Technical specifications
|
| Model: |
KLE 650 Versys |
| Years: |
2007-08 |
|
Engine:
|
Four stroke, parallel twin, DOHC, 4 valves per cylinder
|
|
Capacity:
|
650 cc / 39.6 cu-in
|
|
Bore x Stroke:
|
83 X 60mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
10.6:1
|
|
Induction:
|
Fuel injection: ø38 mm
|
|
Ignition:
|
Digital CBI
|
|
Starting:
|
Electric
|
|
Max Power:
|
47 kW / 64 hp @ 8000 rpm
|
|
Max Torque:
|
61 Nm / 6,2 kgf-m @ 6800 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Diamond, high-tensile steel
|
|
Front Suspension:
|
41 mm inverted telescopic fork with stepless (right-side) adjustable rebound damping and adjustable preload
|
|
Rear Suspension:
|
Offset laydown single-shock with 13-way adjustable rebound damping and 7-way adjustable preload
|
|
Front Brakes:
|
2x 300mm discs 2 piston calipers
|
|
Rear Brakes:
|
Single 220mm disc 1 piston caliper
|
|
Front Tyre:
|
120/70ZR17
|
|
Rear Tyre:
|
160/60ZR17M
|
|
Rake:
|
25°
|
|
Trail:
|
110 mm / 4.3 in
|
|
Dimensions:
|
Length 2126 mm / 83.7 in Width 840 mm / 33.1 in Height 1315.7 mm / 51.8 in
|
|
Wheelbase:
|
1415 mm / 55.7 in
|
|
Seat Height:
|
840 mm / 33.1 in
|
|
Dry Weight:
|
181 kg / 399 lbs
|
|
Fuel Capacity:
|
19 Litres / 5.0 gal
|
|
Consumption Average:
|
19.3 km/lit
|
|
Standing ¼ Mile:
|
13.1 sec / 160.4 km/h
|
|
Standing 1000 m:
|
25.7 sec / 178.2 km/h
|
|
Top Speed:
|
197 km/h / 122.4 mph
|
