Kawasaki KDX 200R (2003-06) technical specifications
Kawasaki KDX 200R is produced in 2003-06. Engine is Two stroke, single cylinder, reed valve, displacement 198 cc / 12.0 cu-in , produces power 37 hp / 27 kW @ 8000 rpm and 34.3 Nm / 25.2 lb-ft @ 7000 rpm. Kawasaki KDX 200R weighs 109 kg / 240 lbs. Kawasaki KDX 200R has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | KDX 200R |
| Years: | 2003-06 |
| Engine: | Two stroke, single cylinder, reed valve |
| Capacity: | 198 cc / 12.0 cu-in |
| Bore x Stroke: | 66 x 58 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 9.4:1 |
| Induction: | Keihin PWK35 carburetor |
| Ignition: | Electronic CDI |
| Starting: | Electric |
| Max Power: | 37 hp / 27 kW @ 8000 rpm |
| Max Torque: | 34.3 Nm / 25.2 lb-ft @ 7000 rpm |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Front Suspension: | 43mm Telescopic forks 20-way compression damping |
| Front Wheel Travel: | 290 mm / 11.4 in |
| Rear Suspension: | Single shock adjustable preload, 20-way compression damping and 18-way rebound damping |
| Rear Wheel Travel: | 300 mm / 11.8 in |
| Front Brakes: | Single 250mm disc 2 piston caliper |
| Rear Brakes: | Single 230mm disc 1 piston caliper |
| Front Tyre: | 80/100-21 |
| Rear Tyre: | 100/100-18 |
| Rake: | 26.5° |
| Wheelbase: | 1435 mm / 56.5 in |
| Seat Height: | 919 mm / 36.2 in |
| Ground Clearance: | 340 mm / 13.4 in |
| Dry Weight: | 109 kg / 240 lbs |
| Fuel Capacity: | 11 Litres / 2.9 US gal |
| Related Link: | Kawasaki KLX |
