Kawasaki GPz 500S / EX 500R Ninja (1987-88) technical specifications
Kawasaki GPz 500S / EX 500R Ninja is produced in 1987-88. Engine is Four stroke, parallel twin cylinders. DOHC, 4 valves per cylinder., displacement 498 cc / 30.4 cu-in , produces power 60 hp / 43.7 kW @ 9800 rpm and 46.1 Nm / 4.7 kg-m @ 8500 rpm. Kawasaki GPz 500S / EX 500R Ninja top speed is 197.9 km/h / 122.9 mph. Kawasaki GPz 500S / EX 500R Ninja weighs 170 kg / 370 lbs. Kawasaki GPz 500S / EX 500R Ninja has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | GPz 500S / EX 500R Ninja |
| Years: | 1987-88 |
| Engine: | Four stroke, parallel twin cylinders. DOHC, 4 valves per cylinder. |
| Capacity: | 498 cc / 30.4 cu-in |
| Bore x Stroke: | 74 x 58 mm |
| Cooling System: | Liquid cooled, |
| Compression Ratio: | 10.8:1 |
| Lubrication: | Wet sump |
| Engine Oil: | Semi-Synthetic, 10W/40 |
| Induction: | 2x Keihin CVK34 carburetor |
| Ignition: | TCI (Transistor Controlled Ignition) |
| Spark Plug: | NGK, DR9EA |
| Starting: | Electric |
| Max Power: | 60 hp / 43.7 kW @ 9800 rpm |
| Max Power Rear Tyre: | 54.7 hp @ 9500 rpm |
| Max Torque: | 46.1 Nm / 4.7 kg-m @ 8500 rpm |
| Clutch: | Wet, multiple discs, cable operated |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Frame: | Iron, Double cradle frame |
| Front Suspension: | 38mm Telescopic forks |
| Front Wheel Travel: | 130 mm / 5.1 in |
| Rear Suspension: | Swinging arm, single shock adjustable for spring preload |
| Rear Wheel Travel: | 100 mm / 3.9 in |
| Front Brakes: | Single 270mm disc 2 piston caliper |
| Rear Brakes: | 160mm drum |
| Front Tyre: | 100/90-16 |
| Rear Tyre: | 120/90-16 |
| Rake: | 63° |
| Trail: | 91 mm / 3.5 in |
| Dimensions: | Length 2110 mm / 83 in Width 685 mm / 27.0 in Height: 1160 mm / 45.6 in |
| Wheelbase: | 1435 mm / 56.5 in |
| Seat Height: | 770 mm / 30.0 in |
| Dry Weight: | 170 kg / 370 lbs |
| Wet Weight: | 200 kg / 441 lbs |
| Fuel Capacity: | 15.9 Litres / 4.2 US gal |
| Consumption Average: | 18.2 km/lit |
| Braking 60 - 0 / 100 - 0: | 14.6 m / 39.9 n |
| Standing ¼ Mile: | 12.5 sec / 164.8 km/h |
| Top Speed: | 197.9 km/h / 122.9 mph |
