Technical specifications
|
| Model: |
ER-5 Twister |
| Years: |
2003-05 |
|
Engine:
|
Four stroke, parallel twin cylinders, DOHC, 4 valves per cylinder.
|
|
Capacity:
|
498 cc / 30.4 cu-in
|
|
Bore x Stroke:
|
74 x 58 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
9.8:1
|
|
Induction:
|
2x 34mm Keihin CVK
|
|
Ignition:
|
Digital
|
|
Starting:
|
Electric
|
|
Max Power:
|
50 hp / 36.5 kW @ 8500 rpm
|
|
Max Torque:
|
45.2 Nm / 33.2 lb-ft @ 7000 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
37 mm telescopic fork
|
|
Front Wheel Travel:
|
125 mm / 4.9 in
|
|
Rear Suspension:
|
Dual rear shocks with 5-way adjustable preload
|
|
Rear Wheel Travel:
|
114 mm / 4.5 in
|
|
Front Brakes:
|
Single 280mm disc 2 piston caliper
|
|
Rear Brakes:
|
160mm drum
|
|
Front Tyre:
|
110/70 R17
|
|
Rear Tyre:
|
130/70 R17
|
|
Wheelbase:
|
1430 mm / 56.3 in
|
|
Seat Height:
|
815 mm / 32.1 in
|
|
Dry Weight:
|
180.0 kg / 396.8
|
|
Fuel Capacity:
|
17 Litres / 4.4 US gal
|
