Technical specifications
|
| Model: |
350 |
| Years: |
1970 |
|
Engine:
|
Two stroke, twin cylinder
|
|
Capacity:
|
343.5 cc / 20.96 cu in
|
|
Bore x Stroke:
|
58 x 65 mm
|
|
Compression Ratio:
|
8.1:1
|
|
Cooling System:
|
Air cooled
|
|
Induction:
|
Carburetor, port control
|
|
Starting:
|
Kick
|
|
Max Power:
|
13.1 kW / 18 hp @ 5000 rpm
|
|
Transmission:
|
4 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
Hydraulic telescopic forks,
|
|
Rear Suspension:
|
Twin shock
|
|
Front Brakes:
|
Expanding drum
|
|
Rear Brakes:
|
Expanding drum
|
|
Front Wheel:
|
3.25-16"
|
|
Rear Wheel:
|
3.50-16"
|
|
Wet Weight:
|
155 kg / 342 lbs
|
|
Fuel Capacity:
|
13.5 L / 3.57 US gal
|
|
Top Speed:
|
120 km/h / 74.6 mph
|
