Indian Chieftain Limited (2017-18) technical specifications

Indian Chieftain Limited is produced in 2017-18. Engine is Four stroke, 49º V-twin, pushrod, Thunder Stroke™ 111, displacement 1811.cc / 110.5 cu-in Indian Chieftain Limited wet weight is 390 kg / 860 lbs. Indian Chieftain Limited has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Chieftain Limited
Years:	2017-18
Engine:	Four stroke, 49º V-twin, pushrod, Thunder Stroke™ 111
Capacity:	1811.cc / 110.5 cu-in
Bore x Stroke:	101 x 113 mm
Compression Ratio:	9.5:1
Exhaust:	Dual exhaust w/ cross-over
Induction:	Electronic Fuel Injection System Closed loop fuel injection / 54mm bore
Starting:	Electric
Max Toque:	119.2 lb-ft / 161.6 Nm @ 2100 rpm
Clutch:	Wet, Multi-Plate
Transmission:	6 Speed
Final Drive:	Belt
Gear Ratio:	1st9.403 : 1 2nd6.411 : 1 3rd4.763 : 1 4th3.796 : 1 5th3.243 : 1 6th2.789 : 1
Final Drive Ratio:	2.2 : 1
Frame:	Cast Aluminum Frame with Integrated Air-Box
Front Suspension:	Telescopic forks,
Front Wheel Travel:	119 mm / 4.7 in
Rear Suspension:	Single shock, with air adjustment
Rear Wheel Travel:	104 mm / 3.7 in
Front Brakes:	2x 300mm floating discs 4 piston calipers
Rear Brakes:	Single 300mm floating disc 2 piston calipers
Front Tyre:	130/60B19
Rear Tyre:	180/60R16
Rake:	25°
Trail:	150 mm / 5.9 in
Dimensions:	Length 2500 mm / 98.7 in Width 1000 mm / 39.42 in Height 1388 mm / 54.6 in
Wheelbase:	1668 mm / 65.7 in
Seat Height:	660 mm / 26.0 in
Ground Clearance:	142 mm / 5.6 in
Wet Weight:	390 kg / 860 lbs
Fuel Capacity:	20.8 Litres / 5.5 US gal
