Indian Chieftain Limited (2017-18) technical specifications
Indian Chieftain Limited is produced in 2017-18. Engine is Four stroke, 49º V-twin, pushrod, Thunder Stroke™ 111, displacement 1811.cc / 110.5 cu-in Indian Chieftain Limited wet weight is 390 kg / 860 lbs. Indian Chieftain Limited has 5 photos.
Technical specifications
+ Add to 'Compare list'Model: | Chieftain Limited |
Years: | 2017-18 |
Engine: | Four stroke, 49º V-twin, pushrod, Thunder Stroke™ 111 |
Capacity: | 1811.cc / 110.5 cu-in |
Bore x Stroke: | 101 x 113 mm |
Compression Ratio: | 9.5:1 |
Exhaust: | Dual exhaust w/ cross-over |
Induction: | Electronic Fuel Injection System Closed loop fuel injection / 54mm bore |
Starting: | Electric |
Max Toque: | 119.2 lb-ft / 161.6 Nm @ 2100 rpm |
Clutch: | Wet, Multi-Plate |
Transmission: | 6 Speed |
Final Drive: | Belt |
Gear Ratio: | 1st9.403 : 1 2nd6.411 : 1 3rd4.763 : 1 4th3.796 : 1 5th3.243 : 1 6th2.789 : 1 |
Final Drive Ratio: | 2.2 : 1 |
Frame: | Cast Aluminum Frame with Integrated Air-Box |
Front Suspension: | Telescopic forks, |
Front Wheel Travel: | 119 mm / 4.7 in |
Rear Suspension: | Single shock, with air adjustment |
Rear Wheel Travel: | 104 mm / 3.7 in |
Front Brakes: | 2x 300mm floating discs 4 piston calipers |
Rear Brakes: | Single 300mm floating disc 2 piston calipers |
Front Tyre: | 130/60B19 |
Rear Tyre: | 180/60R16 |
Rake: | 25° |
Trail: | 150 mm / 5.9 in |
Dimensions: | Length 2500 mm / 98.7 in Width 1000 mm / 39.42 in Height 1388 mm / 54.6 in |
Wheelbase: | 1668 mm / 65.7 in |
Seat Height: | 660 mm / 26.0 in |
Ground Clearance: | 142 mm / 5.6 in |
Wet Weight: | 390 kg / 860 lbs |
Fuel Capacity: | 20.8 Litres / 5.5 US gal |
