Indian Chief Dark Horse (2020) technical specifications

Indian Chief Dark Horse is produced in 2020. Engine is Four stroke, Thunder Stroke™ 116 49˚ V-Twin, displacement 1890 cc / 115 cu in Indian Chief Dark Horse has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Chief Dark Horse
Years:	2020
Engine:	Four stroke, Thunder Stroke™ 116 49˚ V-Twin
Capacity:	1890 cc / 115 cu in
Bore x Stroke:	103.2 x 113 mm
Compression Ratio:	11.0:1
Cooling System:	Air / Oil cooled
Induction:	Electronic fuel injection, closed loop/54 mm bore
Exhaust:	Split dual exhaust with crossover
Battery:	12 volts / 18 amp/hour, 310 CCA
Starting:	Electric
Max Toque:	168 Nm / 126 lb-ft @ 2900 rpm
Clutch:	Wet, Multi-Plate
Transmission:	6 Speed
Final Drive:	Belt drive, 152 tooth
Gear Ratio:	1st 9.403 : 1 2nd 6.411 : 1 3rd 4.763 : 1 4th 3.796 : 1 5th 3.243 : 1 6th 2.789 : 1
Final Drive Ratio:	2.2 : 1
Frame:	Cast Aluminum Frame with Integrated Air-Box
Front Suspension:	46mm cartridge forks with dual rate springs
Front Wheel Travel:	119 mm / 4.7 in
Rear Suspension:	Single shock,
Rear Wheel Travel:	104 mm / 3.7 in
Front Brakes:	2x 300 mm Floating Rotor 4 piston calipers
Rear Brakes:	Single 300 mm Floating Rotor 2 piston calipers
Front Tyre:	Dunlop® American Elite, 130/60B19 61H
Rear Tyre:	Dunlop® American Elite 180/65B16 81H
Front Wheel:	Cast 19″ x 3.5″ with tire pressure monitoring
Rear Wheel:	16″ x 5.0″ with tire pressure monitoring
Rake:	25°
Trail:	150 mm / 5.9 in
Ground Clearance:	139.7 mm / 5.5 in
Dimensions:	Length 2506 mm / 98.7 in
Wheelbase:	1668 mm / 65.7 in
Seat Height:	650 mm / 25.6 in
Dry Weighty:	362 kg / 798 lbs
Fuel Capacity:	20.8 Litres / US 5.5 Gal
