Indian Challenger Elite Limited Edition (2023) technical specifications

Indian Challenger Elite Limited Edition technical specifications

Indian Challenger Elite Limited Edition is produced in 2023. Engine is Four stroke, PowerPlus, 60° V-twin, SOHC, 4 valve per cylinder, displacement 1768 cc / 108 cu-in , produces power 122 hp / 90 kW @ 5500 rpm and 173.5 Nm / 128 lb-ft @ 3800 rpm. Indian Challenger Elite Limited Edition weighs 365 kg / 804 lbs. Indian Challenger Elite Limited Edition has 9 photos.

Technical specifications

+ Add to 'Compare list'
Model: Challenger Elite Limited Edition
Years: 2023
Units: 150
Engine: Four stroke, PowerPlus, 60° V-twin, SOHC, 4 valve per cylinder
Capacity: 1768 cc / 108 cu-in
Bore x Stroke: 108 x 96.5 mm
Compression Ratio: 11.0:1
Cooling System: Liquid cooled
Exhaust: Split dual exhaust with resonator
Lubrication: Semi-dry sump
Induction: Closed loop EFI with 52mm dual-bore throttle bodies
Ignition: Electronic
Starting: Electric
Max Power: 122 hp / 90 kW @ 5500 rpm
Max Torque: 173.5 Nm / 128 lb-ft @ 3800 rpm
Clutch: Wet, multi-plate, assist
Transmission: 6 Speed with overdrive
Gear Ratio: 1st 10.169:1 2nd 6.933:1 3rd 5.151:1 4th 4.105:1 5th 3.508:1 6th 3.017:1
Primary Drive: Gear Drive Wet Clutch
Final Drive: Belt
Final Drive Ratio: 2.379:1
Frame: Cast aluminum
Front Suspension: 43mm Inverted telescopic fork
Front Wheel Travel: 130 mm / 5.1 in
Rear Suspension: Fox Single Shock with electronically controlled hydraulically adjust
Rear Wheel Travel: 114 mm / 4.5 in
Front Brakes: 2x 320mm semi floating rotor discs, with radially mounted Brembo 4 piston caliper
Rear Brakes: Single 298mm floating rotor disc, 2 piston caliper
ABS System: Standard
Front Wheel: 5 Spoke Precision Cut 19 in x 3.5
Rear Wheel: Precision Cut 16 in x 5
Front Tyre: 130/60B19 66H
Rear Tyre: 180/60R16 80H
Rake: 25°
Trail: 150 mm / 5.9 in
Dimensions: Length: 2501 mm / 98.5 in Width: 990 mm / 39.0 in Height: 1428.5 mm / 56.2 in
Wheelbase: 1668 mm / 65.7 in
Seat Height: 672 mm / 26.5 in
Ground Clearance: 137.3 mm / 5.4 in
Dry Weight: 365 kg / 804 lbs
Wet Weight: 381 kg / 839 lbs
Fuel Capacity: 22.7 Litres / 6 US gal
