Technical specifications
|
| Model: |
GT 650S |
| Years: |
2004-06 |
|
Engine:
|
Four stroke, 90° V twin, DOHC, 4 valve per cylinder
|
|
Capacity:
|
647 cc / 39.4 cu-in
|
|
Bore x Stroke:
|
81.5 x 62 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.4:1
|
|
Lubrication:
|
Wet sump
|
|
Engine Oil:
|
Semi-Synthetic, 10W/40
|
|
Induction:
|
38 mm Carburettor
|
|
Ignition:
|
Digital CDI
|
|
Spark Plug:
|
NGK, CR8E
|
|
Starting:
|
Electric
|
|
Max Power:
|
76.4 hp / 58.8 kW @ 9000 rpm
|
|
Max Torque:
|
68 Nm / 6.93 kg-m @ 7500 rpm
|
|
Clutch:
|
Wet, multiple discs, cable operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Steel, double pipe
|
|
Front Suspension:
|
41mm Oil upside down forks
|
|
Front Wheel Travel:
|
120 mm / 4.7 in
|
|
Rear Suspension:
|
Swinging arm
|
|
Rear Wheel Travel:
|
100 mm / 3.9 in
|
|
Front Brakes:
|
2x 300mm discs
|
|
Rear Brakes:
|
Single 230mm disc
|
|
Front Tyre:
|
120/60 -17
|
|
Rear Tyre:
|
160/60 -17
|
|
Dimensions:
|
Length 2060 mm / 81.1 in Width 740 mm / 29.1 in Height 1125 mm / 44.2 in
|
|
Wheelbase:
|
1435 mm / 56.4 in
|
|
Seat Height:
|
780 mm / 30.7 in
|
|
Dry Weight:
|
195 kg / 429 lbs
|
|
Wet Weight:
|
210 kg / 462 lbs
|
|
Fuel Capacity:
|
17 Litres / 3.1 US gal
|
|
Standing ¼ Mile:
|
13.0 sec
|
|
Top Speed:
|
203.8 km/h
|
