Technical specifications
|
| Model: |
FE 350 |
| Years: |
2022 |
|
Engine:
|
Four stroke, single cylinder, DOHC, 4 valves
|
|
Capacity:
|
349.7 cc / 21.3 cu in
|
|
Bore x Stroke:
|
88 x 57.5 mm
|
|
Compression Ratio:
|
13.5:1
|
|
Cooling System:
|
Liquid cooling system, continuous circulation of cooling liquid with water pump
|
|
Lubrication:
|
Forced oil lubrication with 2 Eaton pumps
|
|
Induction:
|
Keihin electronic fuel injection and 42mm throttle body
|
|
EMS:
|
Keihin EMS
|
|
Starting:
|
Electric
|
|
Max Power:
|
45 hp / 32.8 kW
|
|
Clutch:
|
DDS wet multi-disc clutch, Braktec hydraulics
|
|
Transmission:
|
6-speed, claw shifted
|
|
Final Drive:
|
X-Ring 5/8 x 1/4 in chain
|
|
Frame:
|
Central double-cradle-type 25CrMo4 steel
|
|
Front Suspension:
|
48 mm WP XACT-USD
|
|
Front Wheel Travel:
|
300 mm / 11.8 in
|
|
Rear Suspension:
|
WP XACT Monoshock with linkage
|
|
Rear Wheel Travel:
|
300 mm / 11.8 in
|
|
Front Brakes:
|
Single 260 mm disc
|
|
Rear Brakes:
|
Single 220 mm disc
|
|
Front Tyre:
|
90/90-21
|
|
Rear Tyre:
|
140/90-18
|
|
Steering Head Angle:
|
63.5°
|
|
Wheelbase:
|
1482±10 mm / 58.3 in
|
|
Seat Height:
|
950 mm / 37.4 in
|
|
Ground Clearance:
|
360 mm / 14.1 in
|
|
Dry Weight:
|
106.8 kg / 235.4 lbs
|
|
Fuel Capacity:
|
9 Litres / 2.37 US gal
|
