Honda XR 250R (1986) technical specifications

Honda XR 250R is produced in 1986. Engine is Four-stroke, single cylinder SOHC, 4 valve, RFVC (Radial Four Valve Combustion Chamber), displacement 249 cc / 15.1 cu-in , produces power 30 hp / 21.9 kW @ 8500 rpm and 24.5 Nm @ 7000 rpm. Honda XR 250R weighs 105 kg / 231 lbs. Honda XR 250R has 2 photos.

Technical specifications

+ Add to 'Compare list'

Model:	XR 250R
Years:	1986
Engine:	Four-stroke, single cylinder SOHC, 4 valve, RFVC (Radial Four Valve Combustion Chamber)
Capacity:	249 cc / 15.1 cu-in
Bore x Stroke:	75 x 56.5 mm
Cooling System:	Air cooled
Compression Ratio:	10.2:1
Induction:	2x 21mm Keihin carbs
Ignition:	CDI
Spark Plug:	NGK DPR 9Z
Starting:	Kick
Max Power:	30 hp / 21.9 kW @ 8500 rpm
Max Torque:	24.5 Nm @ 7000 rpm
Transmission:	6 Speed
Final Drive:	Chain
Gear Ratio:	1st 2.769 2nd 1.882 3rd 1.380 4th 1.083 5th 0.923 6th 0.814
Front Suspension:	Leading axel air spring 37mm forks
Front Wheel Travel:	254 mm / 10.0 in
Rear Suspension:	Pro-link Kayaba damper adjustment for spring preload and rebound damping
Rear Wheel Travel:	247 mm / 9.6 in
Front Brakes:	Single 240mm disc 2 piston calipers
Rear Brakes:	Drum
Wheels:	Aluminium rim wire spoke
Front Tyre:	80/100-21
Rear Tyre:	110/90-17
Rake:	26°
Trail:	105 mm / 4.1 in
Wheelbase:	1365 mm / 53.7 in
Seat Height:	905 mm / 35.6 in
Ground clearance:	315 mm / 12.4 in
Dimensions:	Length 2035 mm / 80.1 in Width 880 mm / 34.6 in Height 1180 mm / 46.5 in
Dry Weight:	105 kg / 231 lbs
Wet Weight:	112 kg / 247 lbs
Fuel Capacity:	9 Litres / 2.4 gal
