Technical specifications
|
| Model: |
XL 350R |
| Years: |
1986 |
|
Engine:
|
Four stroke, single cylinder, SOHC, 4 valve, RFVC radial valve
|
|
Capacity:
|
339 cc / 26.7 cu-in
|
|
Bore x Stroke:
|
84 x 61.3 mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
9.5;1
|
|
Lubrication:
|
Wet sump
|
|
Induction:
|
2x 26mm Keihin carburetor
|
|
Ignition:
|
CDI
|
|
Starting:
|
Kick
|
|
Max Power:
|
22.4 hp / 16.7 KW @ 7500
|
|
Max Torque:
|
28.3 Nm / 20.9 lb·ft @ 6500 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
41mm Air adjustable forks
|
|
Front Wheel Travel:
|
280 mm / 11.0 in
|
|
Rear Suspension:
|
Single gas shocks, fully adjustable
|
|
Rear Wheel Travel:
|
270 mm / 10.6 in
|
|
Front Brakes:
|
Single disc
|
|
Rear Brakes:
|
Drum
|
|
Front Tyre:
|
3.00 -21
|
|
Rear Tyre:
|
4.60 -17
|
|
Rake:
|
30.5°
|
|
Trail:
|
120 mm / 4.7 in
|
|
Dimensions:
|
860 mm / 33.9 in
|
|
Wheelbase:
|
1410 mm / 55.6 in
|
|
Seat Height:
|
920 mm / 36.2 in
|
|
Wet-Weight:
|
137 kg / 302 lbs
|
|
Fuel Capacity:
|
11 Litres / 2.9 US gal
|
|
Standing ¼ Mile:
|
14.9 sec / 83.6 mph
|
|
Consumption Average:
|
56 mpg
|
|
Top Speed:
|
86 mph
|
