Honda XL 350R (1985) technical specifications
Honda XL 350R is produced in 1985. Engine is Four stroke, single cylinder, SOHC, 4 valve, RFVC radial valve, displacement 339 cc / 26.7 cu-in , produces power 22.4 hp / 16.7 KW @ 7500 and 28.3 Nm / 20.9 lb·ft @ 6500 rpm. Honda XL 350R top speed is 86 mph. Honda XL 350R wet weight is 137 kg / 302 lbs. Honda XL 350R has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | XL 350R |
| Years: | 1985 |
| Engine: | Four stroke, single cylinder, SOHC, 4 valve, RFVC radial valve |
| Capacity: | 339 cc / 26.7 cu-in |
| Bore x Stroke: | 84 x 61.3 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.5;1 |
| Lubrication: | Wet sump |
| Induction: | 2x 26mm Keihin carburetor |
| Ignition: | CDI |
| Starting: | Kick |
| Max Power: | 22.4 hp / 16.7 KW @ 7500 |
| Max Torque: | 28.3 Nm / 20.9 lb·ft @ 6500 rpm |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Front Suspension: | 41mm Air adjustable forks |
| Front Wheel Travel: | 280 mm / 11.0 in |
| Rear Suspension: | Single gas shocks, fully adjustable |
| Rear Wheel Travel: | 270 mm / 10.6 in |
| Front Brakes: | Single disc |
| Rear Brakes: | Drum |
| Front Tyre: | 3.00 -21 |
| Rear Tyre: | 4.60 -17 |
| Rake: | 30.5° |
| Trail: | 120 mm / 4.7 in |
| Dimensions: | 860 mm / 33.9 in |
| Wheelbase: | 1410 mm / 55.6 in |
| Seat Height: | 920 mm / 36.2 in |
| Wet-Weight: | 137 kg / 302 lbs |
| Fuel Capacity: | 11 Litres / 2.9 US gal |
| Standing ¼ Mile: | 14.9 sec / 83.6 mph |
| Consumption Average: | 56 mpg |
| Top Speed: | 86 mph |
