Honda XL 250R (1986) technical specifications
Honda XL 250R is produced in 1986. Engine is Four stroke, single cylinder, SOHC, RFVC, 4 valve, displacement 249 cc / 15.1 cu-in , produces power 20.2 hp / 15 kW @ 7500rpm and 19.6 Nm / 14.5 lb ft @ 8000 rpm. Honda XL 250R weighs 117 kg kg / 258 lbs. Honda XL 250R has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | XL 250R |
| Years: | 1986 |
| Engine: | Four stroke, single cylinder, SOHC, RFVC, 4 valve |
| Capacity: | 249 cc / 15.1 cu-in |
| Bore x Stroke: | 75 x 56.5 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 10.2:1 |
| Induction: | 2 x 24mm piston valve |
| Ignition: | Solid state CD |
| Starting: | Primary kick with automatic compression release |
| Clutch: | Wet multi-plate |
| Max Power: | 20.2 hp / 15 kW @ 7500rpm |
| Max Torque: | 19.6 Nm / 14.5 lb ft @ 8000 rpm |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Front Suspension: | Air assisted telescopic fork |
| Front Wheel Travel: | 210 mm / 8.2 in |
| Rear Suspension: | Single shock, swing arm |
| Rear Wheel Travel: | 109 mm / 4.2 in |
| Front Brakes: | Drum |
| Rear Brakes: | Drum |
| Front Tyre: | 3.00 - 21 |
| Rear Tyre: | 4.60 -17 |
| Wheelbase: | 1379 mm / 54.3 in |
| Seat Height: | 856 mm / 33.7 in |
| Ground Clearance: | 289 mm / 11.4 in |
| Dry Weight: | 117 kg kg / 258 lbs |
| Fuel Capacity: | 10.5 Litres / 2.8 gal |
