Technical specifications
|
| Model: |
X-ADV |
| Years: |
2021 |
|
Engine:
|
Four stroke , Parallel twin, SOHC, 4 valves per cylinder
|
|
Capacity:
|
745 cc / 45.4 cu-in
|
|
Bore x Stroke:
|
77 x 80mm
|
|
Cooling System:
|
Liquid-cooled
|
|
Compression Ratio:
|
10.7:1
|
|
Emission:
|
EURO5
|
|
Induction:
|
PGM-FI electronic fuel injection
|
|
Ignition:
|
Computer-controlled digital transistorised with electronic advance
|
|
Starting:
|
Electric
|
|
Max Power:
|
43.1 kW / 57.8 hp @ 6750 rpm
|
|
Max Torque:
|
69 Nm / 50.9 lb-ft @ 4750 rpm
|
|
Clutch:
|
Wet multiplate hydraulic 2-clutch
|
|
Transmission:
|
6-Speed Dual Clutch Transmission
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Steel Diamond
|
|
Front Suspension:
|
41 mm USD forks
|
|
Front Wheel Travel:
|
120 mm / 4.7 in
|
|
Rear Suspension:
|
Prolink with Rear Shock Preload adjustment
|
|
Rear Wheel Travel:
|
120 mm / 4.7 in
|
|
Front Brakes:
|
2x 296mm discs with 4-piston calipers
|
|
Rear Brakes:
|
Single 240mm disc with single-piston caliper
|
|
ABS:
|
2-channel ABS standard
|
|
Wheels:
|
Spoked
|
|
Front Rim:
|
17 x 3.50
|
|
Rear Rim:
|
15 x 4.50
|
|
Front Tyre:
|
120/70 R17
|
|
Rear Tyre:
|
160/60 R15
|
|
Rake:
|
27˚
|
|
Trail:
|
104 mm / 4.0 in
|
|
Dimensions:
|
Length 2215 mm / 87.2 in Width 940 mm / 37 in Height 1370 mm/ 53.9in
|
|
Wheelbase:
|
1590 mm / 62.6 in
|
|
Seat Height:
|
820 mm / 32.3 in
|
|
Ground Clearance:
|
165 mm / 6.4 in
|
|
Wet Weight:
|
236 kg / 520.2 lbs
|
|
Fuel Capacity:
|
13.2 Litres / 3.4 US gal
|
