Honda VT 750C Shadow Phantom (2014-15) technical specifications
Honda VT 750C Shadow Phantom is produced in 2014-15. Engine is Four stroke, 52° V-twin, SOHC, 6 valve, displacement 745 cc / 45.5 cub in. , produces power 33.5 kW / 44.9 hp @ 5500 rpm and 65 Nm / 6.6 kgf-m / 47.9 lb-ft @ 3500 rpm. Honda VT 750C Shadow Phantom wet weight is 251 kg / 549 lb. Honda VT 750C Shadow Phantom has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | VT 750C Shadow Phantom |
| Years: | 2014-15 |
| Engine: | Four stroke, 52° V-twin, SOHC, 6 valve |
| Capacity: | 745 cc / 45.5 cub in. |
| Bore x Stroke: | 79 x 76 mm |
| Compression Ratio: | 9.6:1 |
| Coooling System: | Liquid cooled |
| Induction: | PGM-FI electronic fuel injection with automatic choke, 34mm throttle body |
| Ignition: | Digital 3-D mapping, two spark plugs per cylinder |
| Starting: | Electric |
| Clutch: | Wet, multiplate with coil springs |
| Max Power: | 33.5 kW / 44.9 hp @ 5500 rpm |
| Max Torque: | 65 Nm / 6.6 kgf-m / 47.9 lb-ft @ 3500 rpm |
| Transmission: | Wide ratio 5 speed |
| Final Drive: | Shaft |
| Gear Ratio: | 1st 2.400 (36/15) / 2nd 1.550 (31/20) / 3rd 1.174 (27/23) / 4th 0.960 (24/25) / 5th 0.852:1 (23/27) |
| Front Suspension: | 41mm telescopic fork |
| Front Wheel Travel: | 117 mm / 4.6 in. |
| Rear Suspension: | Dual conventional dampers with 5-step adjustable spring preload, 90mm wheel travel |
| Rear Wheel Travel: | 90 mm / 3.5 in. |
| Front Brakes: | Single 296 mm disc, 2 piston caliper |
| Rear Brakes: | Single 180 mm drum |
| Front Tyre: | 120/90-17 |
| Rear Tyre: | 160/80-15 |
| Wheelbase: | 1641 mm / 64.6 in. |
| Seat Height: | 655 mm / 25.8 in |
| Wet-Weight: | 251 kg / 549 lb |
| Fuel Capacity: | 14 liters (including 3.5-litre reserve) / 3.7 US gal |
| Consumption Average: | 4.2 L/100 km / 23.8 km/l / 56 US mpg |
