Honda RVF 400R (NC35) (1996) technical specifications
Honda RVF 400R (NC35) is produced in 1996. Engine is Four stroke 90°V-four cylinder, DOHC, 4 valves per cylinder., displacement 399 cc / 24.3 cu-in , produces power 61 hp / 45 kW @ 12500 rpm and 35 Nm / 3.7 kgf-m @ 10000 rpm. Honda RVF 400R (NC35) top speed is 219 km/h / 136.2 mph. Honda RVF 400R (NC35) weighs 165 kg / 363.8 lbs. Honda RVF 400R (NC35) has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | RVF 400R (NC35) |
| Years: | 1996 |
| Engine: | Four stroke 90°V-four cylinder, DOHC, 4 valves per cylinder. |
| Capacity: | 399 cc / 24.3 cu-in |
| Bore x Stroke: | 55 x 42 mm |
| Valve Clearance: | Intake - 0.15 mm / Exhaust 0.24 |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 11.3:1 |
| Lubrication: | Wet sump |
| Engine Oil: | SAE 10W-40 |
| Oil Capacity: | 2.4 Litres |
| Induction: | 4 x 34mm Keihin Carburetors |
| Ignition: | Digitalized full transistor ignition |
| Spark Plug: | NGK ER9EH |
| Starting: | Electric |
| Max Power: | 61 hp / 45 kW @ 12500 rpm |
| Max Torque: | 35 Nm / 3.7 kgf-m @ 10000 rpm |
| Clutch: | Wet, cable operated |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Frame: | Twin-spar aluminum |
| Front Suspension: | 41mm inverted forks: preload and rebound damping |
| Fork oil Per Rod: | 390 ml / SAE 7,5W |
| Rear Suspension: | Rising-rate monoshock. pre-load and rebound damping |
| Front Brakes: | 2 x 269mm 4 piston calipers |
| Rear Brakes: | Single disc 2 piston caliper |
| Front Tyre: | 120/60 R17 |
| Rear Tyre: | 150/60 R17 |
| Rake: | 24° |
| Trail: | 96 mm / 3.7 in |
| Dimensions: | Height 1075 mm / 42.3 in Length 1985 mm / 78.1 in |
| Wheelbase: | 1345 mm / 53.0 in |
| Seat Height: | 780 mm / 30.7 in |
| Dry Weight: | 165 kg / 363.8 lbs |
| Fuel Capacity: | 16 Litres / 3.9 gal |
| Consumption Average: | 42 mpg |
| Standing ¼ Mile: | 12.6 sec / 109 mph |
| Top Speed: | 219 km/h / 136.2 mph |
