Technical specifications
|
| Model: |
Rebel CMX 300 |
| Years: |
2021 |
|
Engine:
|
Four stroke, single cylinder, DOHC; 4 valves per cylinder
|
|
Capacity:
|
286 cc / 17.4 cu-in
|
|
Bore x Stroke:
|
76 x 63 mm
|
|
Cooling System:
|
Liquid-cooled
|
|
Compression Ratio:
|
10.7:1
|
|
Induction:
|
PGM-FI
|
|
Ignition:
|
Computer-controlled digital transistorized w/ electronic advance
|
|
Starting:
|
Electric
|
|
Max Power:
|
NA
|
|
Max Torque:
|
NA
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
#520 chain; 14T/32T
|
|
Front Suspension:
|
41mm Telescopic fork
|
|
Front Wheel Travel:
|
121 mm / 4.8 in
|
|
Rear Suspension:
|
Dual shocks with five-position spring preload adjustment
|
|
Rear Wheel Travel:
|
96 mm / 3.8 in
|
|
Front Brakes:
|
Single 296mm hydraulic disc with two piston caliper
|
|
Rear Brakes:
|
Single 240mm hydraulic disc with single piston caliper
|
|
Front Tyre:
|
130/90-16
|
|
Rear Tyre:
|
150/80-16
|
|
Rake:
|
28°
|
|
Trail:
|
110 mm / 4.3 in
|
|
Dimensions:
|
Length 2189 mm / 86.2 in Height 1089.6 mm / 42.9 in
|
|
Wheelbase:
|
1491 mm / 58.7 in
|
|
Seat Height:
|
691 mm / 27.2 in
|
|
Wet Weight:
|
165 kg / 364 lbs. - ABS: 167.8 kg / 370 lbs
|
|
Fuel Capacity:
|
11.4 Litres / 2.9 US gal
|
