Technical specifications
|
| Model: |
PCX 150 |
| Years: |
2015-16 |
|
Engine:
|
Four stroke, single cylinder, SOHC, 2-valve
|
|
Capacity:
|
153 cc / 9.3 cub in
|
|
Bore x Stroke:
|
58 x 57.9 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
10.6:1
|
|
Exhaust:
|
1-into-1
|
|
Induction:
|
PGM-FI with automatic enrichment
|
|
Ignition:
|
Fully transistorised ignition
|
|
Battery:
|
12 Volt
|
|
Starting:
|
Electric
|
|
Transmission:
|
Honda V-Matic belt converter, automatic
|
|
Final Drive:
|
Belt
|
|
Frame:
|
Steel underbone frame
|
|
Front Suspension:
|
31 mm Hydraulic fork
|
|
Front Wheel Travel:
|
99 mm / 3.9 in
|
|
Rear Suspension:
|
Twin shock
|
|
Rear Wheel Travel:
|
76 mm / 3.0 in
|
|
Front Brakes:
|
Single 220 mm disc, 3-piston caliper and CBS
|
|
Rear Brakes:
|
Drum with CBS
|
|
Wheels:
|
5-Spoke, cast aluminium
|
|
Front Tyre:
|
90/90-14
|
|
Rear Tyre:
|
100/90-14
|
|
Rake:
|
27°
|
|
Trail:
|
86 mm / 3.4 in
|
|
Wheelbase:
|
1316 mm / 51.8 in
|
|
Seat Height:
|
759 mm / 29.9 in
|
|
Wet Weight:
|
130 kg / 286 lbs
|
|
Fuel Capacity:
|
7.9 L / 2.1 US gal
|
