Honda NX 650 Dominator (1990) technical specifications

Honda NX 650 Dominator is produced in 1990. Engine is Four-stroke, single cylinder, SOHC, 4 valve per cylinder, displacement 644 cc / 39.2 cu-in , produces power 45 hp / 33.5 kW @ 6000 rpm and 53 Nm / 5.7 kgf-m @ 5000 rpm. Honda NX 650 Dominator top speed is 160.8 km/h / 100 mph. Honda NX 650 Dominator weighs 163 kg / 359.3 lbs. Honda NX 650 Dominator has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	NX 650 Dominator
Years:	1990
Engine:	Four-stroke, single cylinder, SOHC, 4 valve per cylinder
Capacity:	644 cc / 39.2 cu-in
Bore x Stroke:	100 x 82 mm
Cooling System:	Air cooled
Compression Ratio:	8.3:1
Induction:	Single 40mm Keihin VE-type carburetor
Ignition:	Digital CDI
Starting:	Electric
Spark Plug:	NGK, DPR 8EA-9
Engine Oil:	Semi-Synthetic, 10W/40
Max Power:	45 hp / 33.5 kW @ 6000 rpm
Max Torque:	53 Nm / 5.7 kgf-m @ 5000 rpm
Clutch:	Wet, multiple discs, cable operated
Transmission:	5 Speed
Final Drive:	Chain
Frame:	Steel, Single cradle frame
Front Suspension:	41mm leading-axle fork
Front Wheel Travel:	220 mm / 8.6 in
Rear Suspension:	Pro-Link,
Rear Wheel Travel:	195 mm / 7.6 in
Front Brakes:	Single 256mm disc 2 piston caliper
Rear Brakes:	Single 220mm disc 1 piston caliper
Front Tyre:	90/90–21
Rear Tyre:	120/90–17
Fork Angle:	62°
Trail:	115 mm / 4.5 in
Wheelbase:	1435 mm / 56.4 in
Seat Height:	870 mm / 24.2 in
Ground Clearance:	250 mm / 9.8 in
Dry Weight:	163 kg / 359.3 lbs
Wet Weight:	178 kg / 392.4 lbs
Fuel Capacity:	16 Litres / 4.2 US gal
Consumption Average:	17.8 km/lit
Braking 60 - 0 / 100 - 0:	13.8 m / 40.4 m
Standing ¼ Mile:	13.9 sec / 147.8 km/h
Top Speed:	160.8 km/h / 100 mph
Road Test:	Motosprint Group Test 1990
