Technical specifications
|
| Model: |
Navi 110 |
| Years: |
2022 |
|
Engine:
|
Four stroke, 80° single cylinder, SOHC, 2 valves, with eSP friction-reducing technology
|
|
Capacity:
|
109.2 cc / 6.6 cu-in
|
|
Bore x Stroke:
|
50 x 55.6 mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
9.5:1
|
|
Induction:
|
Carburetor
|
|
Ignition:
|
CDI
|
|
Starting:
|
Electric & kick
|
|
Max Power:
|
5.91 kW / 8 hp @ 7000 rpm
|
|
Max Torque:
|
8.9 Nm / 6.5 lb-ft @ 5500 rpm
|
|
Clutch:
|
Automatic centrifugal dry
|
|
Transmission / Drive:
|
V-Matic with CVT
|
|
Final Drive:
|
Belt
|
|
Frame:
|
Under bone
|
|
Front Suspension:
|
26.8 mm telescopic inverted fork
|
|
Front Wheel Travel:
|
100 mm / 3.9 in
|
|
Rear Suspension:
|
Single shock mounted on left side
|
|
Rear Wheel Travel:
|
71 mm / 2.8 in
|
|
Front Brakes:
|
Single mechanical 130 mm drum, with parking brake
|
|
Rear Brakes:
|
Single mechanical 130 mm drum
|
|
Front Tyre:
|
90/90-12
|
|
Rear Tyre:
|
90/100-10
|
|
Rake:
|
27.5°
|
|
Trail:
|
81 mm / 3.2 in
|
|
Dimensions:
|
Length 1285 mm / 71.1 in Width 739 mm / 29.1 in Height 1044 mm / 41.1 in
|
|
Wheelbase:
|
1285 mm / 50.6 in
|
|
Seat Height:
|
765 mm / 30.1 in
|
|
Ground Clearance:
|
155 mm / 6.1 in
|
|
Wet Weight:
|
107 kg / 236 lbs
|
|
Fuel Capacity:
|
3.4 Litres / 0.9 US gal
|
