Honda GLX 1800 Gold Wing 30th Anniversary (2005) technical specifications
Honda GLX 1800 Gold Wing 30th Anniversary is produced in 2005. Engine is Four stroke, opposed boxer six cylinders, SOHC, 2-valve per cylinder, displacement 1832 cc / 111.8 cub in. , produces power 86 kW /118 hp @ 5500 rpm and 167 Nm / 17.03 kgf-m / 120.9 lb-ft @ 4000 rpm. Honda GLX 1800 Gold Wing 30th Anniversary weighs 362 kg / 799 lbs. Honda GLX 1800 Gold Wing 30th Anniversary has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | GLX 1800 Gold Wing 30th Anniversary |
| Years: | 2005 |
| Engine: | Four stroke, opposed boxer six cylinders, SOHC, 2-valve per cylinder |
| Capacity: | 1832 cc / 111.8 cub in. |
| Bore x Stroke: | 74 x 71 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 9.8:1 |
| Induction: | PGM-FI electronic fuel injection, 40mm throttle bore with automatic choke |
| Ignition: | Computer controlled digital |
| Starting: | Electric |
| Max Power: | 86 kW /118 hp @ 5500 rpm |
| Max Torque: | 167 Nm / 17.03 kgf-m / 120.9 lb-ft @ 4000 rpm |
| Clutch: | Hydraulic |
| Transmission: | 5 Speed |
| Final Drive: | Shaft |
| Gear Ratio: | 1st 2.375 (38/16) / 2nd 1.454 (32/22) / 3rd 1.068 (31/29) / 4th 0.843 (27/32) 5th 0.686 (24/35) |
| Front Suspension: | 45mm fork with anti-dive system |
| Front Wheel Travel: | 140 mm / 5.5 in |
| Rear Suspension: | Pro Arm single-side swingarm with Pro-Link: electronically controlled spring preload adjustment with two memory presets |
| Rear Wheel Travel: | 104 mm / 4.1 in |
| Front Brakes: | 2 x 296 mm discs, 3 piston calipers |
| Rear Brakes: | Single 316 mm disc, 3 piston caliper |
| Front Tyre: | 130/70 R18 |
| Rear Tyre: | 180/60 R16 |
| Rake: | 29.15° |
| Trail: | 109mm / 4.3 in |
| Dimensions: | Length 2630 mm / 103.5 in Width 945 mm / 37.2 in Height 1455 mm / 57.2 in |
| Wheelbase: | 1689 mm / 66.5 in |
| Seat Height: | 740 mm / 29.1 in |
| Ground Clearance: | 125 mm / 4.9 in |
| Dry Weight: | 362 kg / 799 lbs |
| Wet Weight: | 406 - 421 kg / 895 - 928 lbs (depending on specification level) |
| Fuel Capacity: | 25 Liters / 6.6 gal |
