Honda GL 1800 Gold Wing Tour / Automatic-DCT 50th Anniversary (2025) technical specifications

Honda GL 1800 Gold Wing Tour / Automatic-DCT 50th Anniversary technical specifications

Honda GL 1800 Gold Wing Tour / Automatic-DCT 50th Anniversary is produced in 2025. Engine is Four stroke, opposed boxer six cylinders, SOHC, 4-valve per cylinder, finger-follower rocker arm on intake, roller-rocker arm on exhaust, displacement 1833 cc / 111.85 cub in , produces power 93 kW / 124.7 hp @ 5500 rpm and 170 Nm / 125.3 ft-lb @ 4500 rpm. Honda GL 1800 Gold Wing Tour / Automatic-DCT 50th Anniversary wet weight is 393 kg / 866.4 lbs. Honda GL 1800 Gold Wing Tour / Automatic-DCT 50th Anniversary has 7 photos.

Technical specifications

+ Add to 'Compare list'
Model: GL 1800 Gold Wing Tour / Automatic-DCT 50th Anniversary
Years: 2025
Engine: Four stroke, opposed boxer six cylinders, SOHC, 4-valve per cylinder, finger-follower rocker arm on intake, roller-rocker arm on exhaust
Capacity: 1833 cc / 111.85 cub in
Bore x Stroke: 73 x 73 mm
Cooling System: Liquid cooled
Compression Ratio: 10.5:1
Induction: PGM-FI electronic fuel injection, 50mm throttle body
Ignition: Computer controlled digital
Battery: 12V/21Ah
Starting: Integrated Starter Generator system
Max Power: 93 kW / 124.7 hp @ 5500 rpm
Max Torque: 170 Nm / 125.3 ft-lb @ 4500 rpm
Clutch: (MT) Hydraulic, wet, multiplate with coil springs, assist slipper cam (DCT) Hydraulic, wet, multiplate with oil pressure
Transmission: 6 speed MT (including overdrive. Plus electric reverse) 7-speed forward and reverse DCT
Final Drive: Enclosed shaft
Primary Reduction: 1.795 (79/44)
Gear Ratios MT: 1st: 2.200 / 2nd: 1.417 / 3rd: 1.036 / 4th: 0.821 / 5th: 0.667 / 6th: 0.522
Gear Ratios DCT: 1st: 2.167 / 2nd: 1.696 / 3rd: 1.304 / 4th: 1.038 / 5th: 0.821 / 6th: 0.667 / 7th: 0.522 / Rev: 1.190
Final Reduction: Engine side 0.972 Rear Wheel side 2.615
Frame: Aluminum die-cast, twin tube
Front Suspension: Double-wishbone
Front Wheel Travel: 110 mm / 4.3 in
Rear Suspension: Pro-Link system with Showa shock absorber
Rear Wheel Travel: 104 mm / 4.1 in
Front Brakes: 2x 320mm hydraulic discs 6-piston Nissin calipers, floating rotors and sintered metal pads
Rear Brakes: Single 316mm v-entilated disc 3-piston Nissin caliper, sintered metal pads
ABS: Electronically controlled combined ABS system
Front Rim: 3.5 x 18
Rear Rim: 6.0 x 16
Front Tyre: 130/70R18 M/C 63H
Rear Tyre: 200/55R16 M/C 77H
Rake: 30.5?
Trail: 109 mm / 4.3 in
Dimensions: Length: 2615 mm / 102.9 in Width: DCT 905 mm / 35.6 in / MT 925 mm / 36.4 in Height: 1430 mm / 56.2 in
Wheelbase: 1695 mm / 66.7 in
Seat Height: 745 mm / 29.3 in
Ground Clearance: 130 mm / 5.11 in
Wet Weight: 393 kg / 866.4 lbs
Fuel Capacity: 21.1 Litres / US 5.57 gal
