Technical specifications
|
| Model: |
FJS 600 Silver Wing / ABS (SW T-600GT) |
| Years: |
2006-09 |
|
Engine:
|
Four stroke, parallel twin, DOHC, 4 valves per cylinder
|
|
Capacity:
|
582 cc / 35.5 cub in
|
|
Bore x Stroke:
|
72 x 71.5 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
10.2:1
|
|
Exhaust:
|
2-into-1
|
|
Induction:
|
PGM-FI with automatic enrichment circuit, 4-hole injectors
|
|
Ignition:
|
Computer controlled fully transistorised with electronic advance
|
|
Starting:
|
Electric
|
|
Max Power:
|
50 hp / 36.5 kW @ 7500 rpm
|
|
Max Torque:
|
54 Nm / 39.8 lb-ft @ 6000 rpm
|
|
Transmission:
|
Automatic V-Matic
|
|
Final Drive:
|
Belt
|
|
Front Suspension:
|
41 mm Telescopic fork
|
|
Front Wheel Travel:
|
107 mm / 4.2 in
|
|
Rear Suspension:
|
Swingarm with dual shocks, 5-positionspring preload adjustable
|
|
Rear Wheel Travel:
|
114 mm / 4.5 in
|
|
Front Brakes:
|
Single 256mm disc 3 piston calipers ABS
|
|
Rear Brakes:
|
Single 220mm disc 2 piston caliper ABS
|
|
Front Tyre:
|
120/80-14
|
|
Rear Tyre:
|
150/70-13
|
|
Wheelbase:
|
1600 mm / 63 in
|
|
Seat Height:
|
754 mm / 27.9 in
|
|
Wet Weight:
|
245 kg / 541 lbs
|
|
Fuel Capacity:
|
16 Litres / 4.2 US gal
|
|
Average Consumption:
|
16.1 km/lit
|
|
Standing ¼ Mile:
|
15.9 sec
|
|
Top Speed:
|
161.2 km/h / 100 mph
|
