Honda CBR 900RR Fireblade (CBR954RR) (2003) technical specifications

Honda CBR 900RR Fireblade (CBR954RR) is produced in 2003. Engine is Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, displacement 954cc / 58.2 cub. in , produces power 113 kW / 154 hp @ 11250rpm and 101 Nm / 10.3 kg fm / 74.6 lb.ft @ 9000rpm. Honda CBR 900RR Fireblade (CBR954RR) top speed is 286 km/h / 178 mph. Honda CBR 900RR Fireblade (CBR954RR) weighs 168 kg / 370 lbs. Honda CBR 900RR Fireblade (CBR954RR) has 6 photos.

Technical specifications

+ Add to 'Compare list'

Model:	CBR 900RR Fireblade (CBR954RR)
Years:	2003
Engine:	Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder
Capacity:	954cc / 58.2 cub. in
Bore x Stroke:	75 x 54 mm
Compression Ratio:	11.5:1
Cooling System:	Liquid cooling
Lubrication:	Wet sump
Engine oil:	Synthetic, 10W/40
Exhaust:	Stainless steel, 4 into 2 into 1 with titanium muffler
Induction:	PGM-FI (fuel-injection) with automatic choke
Ignition:	Computer-controlled digital, 3D mapping
Starting:	Electronic
Spark Plug:	NGK, IMR9C-9H
Max Power:	113 kW / 154 hp @ 11250rpm
Max Torque:	101 Nm / 10.3 kg fm / 74.6 lb.ft @ 9000rpm
Clutch:	Nine-plate clutch with durable friction plate material
Transmission:	6 Speed
Final Drive:	# 530 chain, O-ring sealed drive chain, 108 links
Gear Ratio:	1st 2.73 / 2nd 2.00 / 3rd 1.60 / 4th 1.37 / 5th 1.23 / 6th 1.13:1
Frame:	Twin-spar extruded aluminum frame with a pivotless swingarm design utilizing a cast aluminum bracket attached to the swingarm pivots.
Front Suspension:	43mm inverted telescopic fork with stepless preload, compression and rebound adjustment
Front Wheel Travel:	120 mm / 4.7 in.
Rear Suspension:	Pro-Link with gas-charged H.M.A.S. damper featuring 13-step preload and stepless compression and rebound damping adjustment
Rear Wheel Travel:	135 mm / 5.3 in.
Front Brakes:	2x 330 mm discs 4 piston calipers
Rear Brakes:	Single 220mm disc 1 piston caliper
Front Rim:	Aluminium alloy hollow spoke, 89 mm / 3.5 in.
Front Tyre:	120/70 ZR17
Rear Rim:	Aluminium alloy hollow spoke, 152 mm / 6.0 in.
Rear Tyre:	190/50 ZR17
Rake:	23,8°
Trail:	97 mm / 3.8 in.
Dimensions:	Length 2025 mm / 79.7 in Width 680 mm / 26.8 in Height 1135 mm / 44.7 in
Wheelbase:	1400 mm / 55.1 in.
Ground Clearance:	130 mm / 5.1 in.
Seat Height:	815 mm / 32.1 in.
Dry Weight:	168 kg / 370 lbs
Wet Weight:	192 kg / 424 lb
Fuel Capacity:	18 Litres / 4.8 US gal
Average Consumption:	5.6 l/100 km / 18 km/l / 42.5 mpg
Standing ¼ mile:	10.4 sec / 214 km/h / 133 mph
Top Speed:	286 km/h / 178 mph
Colours:	AndesBlue Metallic (with red and white) Black (with gunpowder matte black) Lapis Blue Metallic (with yellow and white)
