Technical specifications
|
| Model: |
CBR 600F |
| Years: |
1990 |
|
Engine:
|
Four stroke, Transverse four cylinder, DOHC, 4 valve per cylinder.
|
|
Capacity:
|
598 cc / 36.4 cu-in
|
|
Bore x Stroke:
|
63 x 48 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.3:1
|
|
Lubrication:
|
Wet sump
|
|
Induction:
|
4x 32mm Keihin CV carbs
|
|
Ignition:
|
Digital
|
|
Staring:
|
Electric
|
|
Max Power:
|
85 hp / 62 kW @ 95000 rpm (rear tyre 74.0 hp @ 10800 rpm)
|
|
Max Torque:
|
59 Nm / 44 lb-ft @ 8500 rpm
|
|
Transmission :
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Steel, Single cradle frame
|
|
Front Suspension:
|
37mm Showa telescopic forks with air assistance and non adjustable TRAC.
|
|
Rear Suspension:
|
Pro-link rising rate monoshock with 7 position preload.
|
|
Front Brakes:
|
2x 276mm discs 2 piston calipers
|
|
Rear Brakes:
|
Single 218mm disc 1 piston caliper
|
|
Front Tyre:
|
110/80 R17
|
|
Rear Tyre:
|
130/80 R17
|
|
Dimensions:
|
Length 2130 mm / 83.8 in
|
|
Wheelbase:
|
1410 mm / 55.5 in
|
|
Seat Height:
|
770 mm / 30.3 in
|
|
Dry Weight:
|
182 kg / 397 lbs
|
|
Wet Weight:
|
199 kg / 439 lbs
|
|
Fuel Capacity:
|
16.5 Litres / 3.7 gal
|
|
Consumption Average:
|
18.7 km/lit
|
|
Braking 60 - 0 / 100 - 0:
|
12.98 / 36.19m
|
|
Standing
ΒΌ Mile :
|
11.63 sec / 185.1 km/h
|
|
Top Speed:
|
233.5 km/h
|
|
Road Tests:
|
Motosprint 1989 Motosprint Group Test I 1989 Motosprint Group Test II 1989 Motosprint Group Test III 1989
|
