Technical specifications
|
| Model: |
CBR 125R |
| Years: |
2010 |
|
Engine:
|
Four stroke single cylinder, SOHC, 2 valve.
|
|
Capacity:
|
124.7 cc / 7.6 cu-in
|
|
Bore x Stroke:
|
58 x 47.2 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.0:1
|
|
Lubrication:
|
Wet sump
|
|
Engine Oil:
|
Semi-Synthetic, 10W/30
|
|
Induction:
|
PGM-FI electronic fuel injection
|
|
Ignition:
|
Fully transistorised with electronic advance
|
|
Starting:
|
Electric
|
|
Max Power:
|
13.6 hp / 10 kW @ 10000 rpm
|
|
Max Torque:
|
10.6 Nm / 1.08 kg-m @ 8250 rpm
|
|
Clutch:
|
Wet, multiple discs, cable operated
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Frame:
|
Steel, Double cradle frame
|
|
Front Suspension:
|
31mm telescopic fork,
|
|
Front Wheel Travel:
|
109 mm / 4.2 in
|
|
Rear Suspension:
|
Monoshock damper,
|
|
Rear Wheel Travel:
|
120 mm / 4.7 in
|
|
Front Brakes:
|
Single 276mm disc 2 piston caliper
|
|
Rear Brakes:
|
Single 220mm disc 1 piston caliper
|
|
Front Tyre:
|
80/80 –17
|
|
Rear Tyre:
|
100/80 –17
|
|
Rake:
|
25°
|
|
Trail:
|
88 mm / 3.4 in
|
|
Dimensions:
|
Length 1920 mm / 75.5 in Width 675 mm / 26.5 in Height 1070 mm / 42.2 in
|
|
Wheelbase:
|
1294 mm / 50.9 in
|
|
Seat Height:
|
776 mm / 30.6 in
|
|
Ground Clearance:
|
172 mm / 6.8 in
|
|
Dry Weight:
|
115 kg / 253.5 lbs
|
|
Wet Weight:
|
127 kg / 280.0 lbs
|
|
Fuel Capacity:
|
10 Litres / 2.6 gal
|
|
Standing ¼ Mile:
|
19.9 sec
|
|
Top Speed:
|
112.7 km/h / 70 mph
|
