Honda CBR 125R (2009) technical specifications
Honda CBR 125R is produced in 2009. Engine is Four stroke single cylinder, SOHC, 2 valve., displacement 124.7 cc / 7.6 cu-in , produces power 13.6 hp / 10 kW @ 10000 rpm and 10.6 Nm / 1.08 kg-m @ 8250 rpm. Honda CBR 125R top speed is 112.7 km/h / 70 mph. Honda CBR 125R weighs 115 kg / 253.5 lbs. Honda CBR 125R has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | CBR 125R |
| Years: | 2009 |
| Engine: | Four stroke single cylinder, SOHC, 2 valve. |
| Capacity: | 124.7 cc / 7.6 cu-in |
| Bore x Stroke: | 58 x 47.2 mm |
| Cooling System: | Liquid cooled |
| Compression Ratio: | 11.0:1 |
| Lubrication: | Wet sump |
| Engine Oil: | Semi-Synthetic, 10W/30 |
| Induction: | PGM-FI electronic fuel injection |
| Ignition: | Fully transistorised with electronic advance |
| Starting: | Electric |
| Max Power: | 13.6 hp / 10 kW @ 10000 rpm |
| Max Torque: | 10.6 Nm / 1.08 kg-m @ 8250 rpm |
| Clutch: | Wet, multiple discs, cable operated |
| Transmission: | 6 Speed |
| Final Drive: | Chain |
| Frame: | Steel, Double cradle frame |
| Front Suspension: | 31mm telescopic fork, |
| Front Wheel Travel: | 109 mm / 4.2 in |
| Rear Suspension: | Monoshock damper, |
| Rear Wheel Travel: | 120 mm / 4.7 in |
| Front Brakes: | Single 276mm disc 2 piston caliper |
| Rear Brakes: | Single 220mm disc 1 piston caliper |
| Front Tyre: | 80/80 –17 |
| Rear Tyre: | 100/80 –17 |
| Rake: | 25° |
| Trail: | 88 mm / 3.4 in |
| Dimensions: | Length 1920 mm / 75.5 in Width 675 mm / 26.5 in Height 1070 mm / 42.2 in |
| Wheelbase: | 1294 mm / 50.9 in |
| Seat Height: | 776 mm / 30.6 in |
| Ground Clearance: | 172 mm / 6.8 in |
| Dry Weight: | 115 kg / 253.5 lbs |
| Wet Weight: | 127 kg / 280.0 lbs |
| Fuel Capacity: | 10 Litres / 2.6 gal |
| Standing ¼ Mile: | 19.9 sec |
| Top Speed: | 112.7 km/h / 70 mph |
