Honda CBR 125R (2005) technical specifications

Honda CBR 125R is produced in 2005. Engine is Four stroke single cylinder, SOHC, 2 valve., displacement 124.7 cc / 7.6 cu-in , produces power 13.6 hp / 10 kW @ 10000 rpm and 10.6 Nm / 1.08 kg-m @ 8250 rpm. Honda CBR 125R top speed is 112.7 km/h / 70 mph. Honda CBR 125R weighs 115 kg / 253.5 lbs. Honda CBR 125R has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	CBR 125R
Years:	2005
Engine:	Four stroke single cylinder, SOHC, 2 valve.
Capacity:	124.7 cc / 7.6 cu-in
Bore x Stroke:	58 x 47.2 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.0:1
Lubrication:	Wet sump
Engine Oil:	Semi-Synthetic, 10W/30
Induction:	28mm VK-type carburetor
Ignition:	Capacitor Discharge (CDI)
Spark Plug:	NGK, CR8E
Starting:	Electric
Max Power:	13.6 hp / 10 kW @ 10000 rpm
Max Torque:	10.6 Nm / 1.08 kg-m @ 8250 rpm
Clutch:	Wet, multiple discs, cable operated
Transmission:	6 Speed
Final Drive:	Chain
Frame:	Steel, Double cradle frame
Front Suspension:	31mm telescopic fork,
Front Wheel Travel:	109 mm / 4.2 in
Rear Suspension:	Monoshock damper,
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	Single 276mm disc 2 piston caliper
Rear Brakes:	Single 220mm disc 1 piston caliper
Front Tyre:	80/80 –17
Rear Tyre:	100/80 –17
Rake:	25°
Trail:	88 mm / 3.4 in
Dimensions:	Length 1920 mm / 75.5 in Width 675 mm / 26.5 in Height 1070 mm / 42.2 in
Wheelbase:	1294 mm / 50.9 in
Seat Height:	776 mm / 30.6 in
Ground Clearance:	172 mm / 6.8 in
Dry Weight:	115 kg / 253.5 lbs
Wet Weight:	127 kg / 280.0 lbs
Fuel Capacity:	10 Litres / 2.6 gal
Standing ¼ Mile:	19.9 sec
Top Speed:	112.7 km/h / 70 mph
