Honda CBR 1100XX Super Blackbird (2002) technical specifications

Honda CBR 1100XX Super Blackbird is produced in 2002. Engine is Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder., displacement 1137 cc / 69.3 cu-in , produces power 164 hp / 112 kW @ 10000 rpm and 124 Nm / 12.6 kg-fm 91.5 ft.lb @ 7250 rpm. Honda CBR 1100XX Super Blackbird top speed is 303 km/h / 188.2 mph. Honda CBR 1100XX Super Blackbird weighs 223 kg / 490 lbs. Honda CBR 1100XX Super Blackbird has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	CBR 1100XX Super Blackbird
Years:	2002
Engine:	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
Capacity:	1137 cc / 69.3 cu-in
Bore x Stroke:	79 x 58 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.0:1
Lubrication:	Wet sump
Engine Oil:	Synthetic, 10W/40
Oil Capacity:	4.6 Liters / 4.9 quarts
Exhaust:	System Layout 4-1-2 into 2 (all models) 4-1-2 into 2 with 3 catalytic converters (2001
Induction:	Keihin Electronic Fuel Injection 42 mm Throttle Body
Ignition :	Computer-controlled digital transistorized
Spark Plug:	NGK, CR9EHVX-9
Starting:	Electric
Max Power:	164 hp / 112 kW @ 10000 rpm
Max Power Rear Tyre:	141.4 hp @ 10100 rpm
Max Torque:	124 Nm / 12.6 kg-fm 91.5 ft.lb @ 7250 rpm
Engine Redline:	11800 rpm
Clutch:	Hydraulic wet multi plate
Transmission :	6 Speed
Final Drive:	‘O’ or ‘X’ ring Chain
Primary Drive Gear Teeth Ratio:	56/ 88 (1.571:1)
Final Drive Sprocket Teeth Ratio:	17/ 45 (2.647:1)
Gear Ratio:	6th 25/ 24 (1.042:1) 5th 28/ 24 (1.167:1) 4th 28/ 21 (1.333:1) 3rd 30/ 19 (1.579:1) 2nd 32/ 16 (2.000:1) 1st 36/ 13 (2.769:1)
Frame:	Aluminium twin spar
Front Suspension:	43mm H.M.A.S. Cartridge-type fork,
Front Wheel Travel:	120 mm / 4.7 in
Rear Suspension:	Pro-Link single shock with spring preload and rebound damping adjustability,
Rear Wheel Travel:	120 mm / 4.7 in
Front Brakes:	2x 310mm discs 3 piston calipers
Rear Brakes:	Single 256mm disc 3 piston caliper
Front Tyre:	120/70 ZR17
Rear Tyre:	180/55 ZR17
Rake:	25°
Trail:	99 mm / 3.8 in
Dimensions:	Length 2,160mm / 85.0in Width 720mm / 28.4in Height 1,170m / 46.1in
Wheelbase:	1490 mm / 58.6 in
Seat Height:	810 mm / 31.9 in
Ground Clearance:	130 mm / 5.1 in
Dry Weight:	223 kg / 490 lbs
Wet Weight:	254 kg / 559 lbs
Fuel Capacity :	24 Litres / 5.2 gal
Consumption Average:	16.5 km/lit
Braking 60 - 0 / 100 - 0:	12.2 m / 37.8 m
0-100 km/h:	2.4 sec
0-140 km/h:	4.6 sec
0-200 km/h:	9.2 sec
Acceleration in 3rd gear (6th gear)100-160 km/h:	3,2 (6,7) sec
Standing ¼ Mile :	10.0 sec / 214 km/h
Top Speed:	303 km/h / 188.2 mph
Road Test:	Honda CBR1100 Kawasaki ZZR1100 1997 Motosprint
