Technical specifications
|
| Model: |
CBF 600N |
| Years: |
2010-11 |
|
Engine:
|
Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
|
|
Capacity:
|
599 cc / 36.5 cu-in
|
|
Bore x Stroke:
|
67.0 x 42.5 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11.6:1
|
|
Induction:
|
Electronic fuel injection 32mm throttle body
|
|
Ignition:
|
Computer-controlled digital transistorized
|
|
Starting:
|
Electreic
|
|
Max Power:
|
55.8 kW / 76.4 hp @ 10500 rpm
|
|
Max Torque:
|
58 Nm / 43.5 ft.lb @ 8000 rpm
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Chain
|
|
Front Suspension:
|
41mm telescopic fork
|
|
Front Wheel Travel:
|
120 mm / 4.7 in
|
|
Rear Suspension:
|
Monoshock damper with 7-step adjustable preload.
|
|
Rear Wheel Travel:
|
125 mm / 4.9 in
|
|
Front Brakes:
|
2x 296mm discs 3 piston calipers (ABS)
|
|
Rear Brakes:
|
Single 240mm disc 1 piston caliper (ABS)
|
|
Front Tyre:
|
120/70 ZR17
|
|
Rear Tyre:
|
160/60 ZR17
|
|
Dimensions:
|
Height 2160 mm / 85.0 in Length 2160 mm / 85.0 in
|
|
Wheelbase:
|
1490 mm / 58.7 in
|
|
Seat Height:
|
785 mm / 30.9 in
|
|
Ground Clearance:
|
130 mm /5.1 in
|
|
Dry Weight:
|
213 kg / 469.6 lbs
|
|
Fuel Capacity:
|
20 Litres / 5.2 US gal
|
|
Consumption Average:
|
22.3 km/lit
|
|
Standing ¼ Mile:
|
12.6 sec
|
|
Top Speed:
|
199.8 km/h / 125 mph
|
