Honda CB 125 Disc (1982) technical specifications
Honda CB 125 Disc is produced in 1982. Engine is Four stroke, twin cylinder, OHC, 2 valve per cylinder, displacement 124 cc / 7.6 cu-in , produces power 17 hp / 12.4 kW @ 11500 rpm and NA. Honda CB 125 Disc weighs 133 kg / 295.4 lbs. Honda CB 125 Disc has 1 photos.
Technical specifications
+ Add to 'Compare list'| Model: | CB 125 Disc |
| Years: | 1982 |
| Engine: | Four stroke, twin cylinder, OHC, 2 valve per cylinder |
| Capacity: | 124 cc / 7.6 cu-in |
| Bore x Stroke: | 44 x 41mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 7.4:1 |
| Induction: | 2x Keihin 22mm slide type manual choke |
| Ignition: | CDI |
| Starting: | Kick |
| Max Power: | 17 hp / 12.4 kW @ 11500 rpm |
| Max Torque: | NA |
| Clutch: | Multi-disc, wet |
| Transmission: | 5 Speed |
| Final Drive: | Chain |
| Gear Ratio: | 5th 9.46 / 4th 11.10 / 3rd 13.72 / 2nd 17.81 / 1st 26.20 |
| Front Suspension: | Telescopic fork, 4.5 in wheel travel. |
| Rear Suspension: | Swing arm, 2.6 in wheel travel |
| Front Tyre: | 2.50 -18 |
| Rear Tyre: | 2.75 -18 |
| Dry-Weight: | 133 kg / 295.4 lbs |
| Fuel Capacity: | 10 Litres / 10.6 US gal |
