Honda CB 1100 (2011) technical specifications

Honda CB 1100 is produced in 2011. Engine is Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder., displacement 1140 cc/ 69.5 cu-in , produces power 66 kW / 88.5 hp @ 7500 rpm and 93 Nm / 68.5 lb-ft @ 5000 rpm. Honda CB 1100 wet weight is 247 kg / 544 lbs. Honda CB 1100 has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	CB 1100
Years:	2011
Engine:	Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.
Capacity:	1140 cc/ 69.5 cu-in
Bore x Stroke:	73.5 x 67.2 mm
Cooling System:	Air cooled
Compression Ratio:	9.5:1
Induction:	PGM-FI electronic fuel injection Throttle Bore 32mm
Lubrication:	Wet sump
Oil capacity:	4.9 Litres
Ignition:	Full-transistor battery ignition / electric
Spark Plug:	NGK LMAR8A - 9S
Battery:	YTZ14S WET 12V-11.2Ah
Starting:	Electric
Max Power:	66 kW / 88.5 hp @ 7500 rpm
Max Torque:	93 Nm / 68.5 lb-ft @ 5000 rpm
Clutch:	Multi-plate wet clutch
Transmission:	5 Speed
Final Drive:	Chain 2.166 (39/18)
Frame:	Type Double steel cradle
Turning Radius:	2.7m
Front Suspension:	41mm conventional fork
Front Wheel Travel:	106 mm / 4.2 in
Rear Suspension:	Spring preload adjustable, Dual shocks
Rear Wheel Travel:	114.3 mm / 4.5 in
Front Brakes:	2x 296mm discs 4 piston calipers
Rear Brakes:	Single 256mm disc
Front Tyre:	110/80 R18
Rear Tyre:	140/70 -R18
Trail:	114 mm / 4.4 in
Caster:	27°
Dimensions:	Length 2195 mm / 86.4 Width 835 mm / 32.8 in Height 1130 mm / 44.4 in
Wheelbase:	1490 mm / 58.7 in
Seat Height:	795 mm / 31.2 in
Wet Weight:	247 kg / 544 lbs
Fuel Capacity:	14.6 Litres / 3.9 gal
Reserve:	3.5 Litres
