Harley-Davidson Harley Davidson XLH 900 Sportster (1969-71) technical specifications
Harley-Davidson Harley Davidson XLH 900 Sportster is produced in 1969-71. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder., displacement 882 cc / 53.8 cu-in , produces power 65 hp / 47.4 kW @ 6800 rpm and NA. Harley-Davidson Harley Davidson XLH 900 Sportster has 1 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson XLH 900 Sportster |
| Years: | 1969-71 |
| Engine: | Four stroke, 45° V-Twin, OHV, 2 valves per cylinder. |
| Capacity: | 882 cc / 53.8 cu-in |
| Bore x Stroke: | 76.2 x 96.8 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.0:1 |
| Lubrication: | Dry sump |
| Induction: | Single 1.625 in., Williston |
| Ignition: | Magnetic |
| Starting: | Kick |
| Max Power: | 65 hp / 47.4 kW @ 6800 rpm |
| Max Torque: | NA |
| Clutch: | Wet, multiple discs, cable operated |
| Transmission: | 4 Speed |
| Final Drive: | Chain |
| Front Suspension: | Cartridge |
| Rear Suspension: | Dual shocks swinging arm fork |
| Front Brakes: | 200mm drum |
| Rear Brakes: | 200mm drum |
| Front Tyre: | 3.75-19 |
| Rear Tyre: | 4.25-18 |
| Weight: | 214 kg / 471.8 lbs |
| Fuel Capacity: | 8.5 Litres / 2.2 US gal |
