Harley-Davidson Harley Davidson XL 883L Sportster SuperLow (2015) technical specifications

Harley-Davidson Harley Davidson XL 883L Sportster SuperLow is produced in 2015. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder., displacement 883 cc / 53.9 cub in. , produces power 50.2 kW / 68 hp @ 4400 rpm and 73 Nm / 7.4 kgf-m / 53.8 ft/lb @ 3750 rpm. Harley-Davidson Harley Davidson XL 883L Sportster SuperLow weighs 244 kg / 537 lbs. Harley-Davidson Harley Davidson XL 883L Sportster SuperLow has 5 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson XL 883L Sportster SuperLow
Years:	2015
Engine:	Four stroke, 45° V-Twin, OHV, 2 valves per cylinder.
Capacity:	883 cc / 53.9 cub in.
Bore x Stroke:	76.2 x 96.8 mm
Cooling System:	Air cooled
Compression Ratio:	9.0:1
Exhaust:	Chrome, staggered, shorty exhaust with dual mufflers
Induction:	Electronic Sequential Port Fuel Injection
Ignition:	Digital CDI
Starting:	Electric
Max Power:	50.2 kW / 68 hp @ 4400 rpm
Max Torque:	73 Nm / 7.4 kgf-m / 53.8 ft/lb @ 3750 rpm
Clutch:	Multi-plate clutch with diaphragm spring in oil bath
Transmission:	5 Speed
Primary Drive:	Chain, 34/57
Final Drive:	Belt
Gear Ratio:	1st 10.407 / 2nd 7.436 / 3rd 5.53 / 4th 4.583 / 5th 3.93:1
Frame:	Mild steel, tubular frame, circular sections, cast junctions Swingarm Mild steel, rectangular tube sections, stamped junctions, MIG welded
Lean Angle, Left:	24.4º
Lean Angle, Right:	24.7º
Front Suspension:	39 mm Telescopic forks
Front Wheel Travel:	104 mm / 4.09 in
Rear Suspension:	Coil-over, dual-adjustable preload
Rear Wheel Travel:	64 mm / 2.5 in
Front Brakes:	Single 300 mm disc, 2 x 38mm piston calipers
Rear Brakes:	Single 260 mm disc, 2 x 38mm piston calipers
Front Wheel:	Black, Split 5-Spoke with Machined Rim
Rear Wheel:	Black, Split 5-Spoke with Machined Rim
Front Tyre:	120/70 ZR-18 59W
Rear Tyre:	150/60 ZR-17 66W
Rake:	31.1°
Trail:	145 mm / 5.7 in
Dimensions:	Length 2225 mm / 87.6 in
Wheelbase:	1500 mm / 59.1 in
Ground Clearance:	99 mm / 3.9 in
Seat Height:	Laden 648 mm / 25.5 in Unladen 696 mm / 27.4 in
Gross Vehicle Weight Rating:	453.6 kg / 1000 lbs
Dry Weight:	244 kg / 537 lbs
Wet Weight:	256 kg / 565 lbs
Oil Capacity:	2.7 Litres / 2.8 US qrts
Fuel Capacity:	17 Litres / 4.5 US gal
Average Consumption:	4.6 L/100 km / 21.7 km/l / 51 US mpg
