Harley-Davidson Harley Davidson XL 883L Sportster SuperLow (2013) technical specifications

Harley-Davidson Harley Davidson XL 883L Sportster SuperLow technical specifications

Harley-Davidson Harley Davidson XL 883L Sportster SuperLow is produced in 2013. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder., displacement 883 cc / 53.9 cub in. , produces power 68 hp / 50.2 kW @ 4400 rpm and 73 Nm / 53.8 ft/lb @ 4100 rpm. Harley-Davidson Harley Davidson XL 883L Sportster SuperLow weighs 234 kg / 536 lbs. Harley-Davidson Harley Davidson XL 883L Sportster SuperLow has 3 photos.

Technical specifications

+ Add to 'Compare list'
Model: Harley Davidson XL 883L Sportster SuperLow
Years: 2013
Engine: Four stroke, 45° V-Twin, OHV, 2 valves per cylinder.
Capacity: 883 cc / 53.9 cub in.
Bore x Stroke: 76.2 x 96.8 mm
Cooling System: Air cooled
Compression Ratio: 8.8:1
Exhaust: Chrome, staggered, shorty exhaust with dual mufflers
induction: Electronic Sequential Pot Fuel Injection
Ignition: Digital CDI
Starting: Electric
Max Power: 68 hp / 50.2 kW @ 4400 rpm
Max Torque: 73 Nm / 53.8 ft/lb @ 4100 rpm
Clutch: Multi-plate clutch with diaphragm spring in oil bath
Transmission: 5 Speed
Final Drive: Belt
Gear Ratio: 1st 10.407 2nd 7.436 3rd 5.53 4th 4.583 5th 3.93
Frame: Mild steel, tubular frame, circular sections, cast junctions Swingarm Mild steel, rectangular tube sections, stamped junctions, MIG welded
Front Suspension: 39mm Forks
Front Wheel Travel: 104 mm / 4.09 in
Rear Suspension: Coil-over, dual-adjustable preload
Rear Wheel Travel: 64 mm / 2.5 in
Front Brakes: Single 300mm disc 2 38mm piston calipers
Rear Brakes: Single 260mm disc 2 38mm piston calipers
Front Wheel: Black, Split 5-Spoke with Machined Rim
Rear Wheel: Black, Split 5-Spoke with Machined Rim
Front Tyre: 120/70 ZR-18 59W
Rear Tyre: 150/60 ZR-17 66W
Rake: 31.1°
Trail: 145 mm / 5.7 in
Dimensions: Length 2215 mm / 87.2 in
Wheelbase: 1500 mm / 59.1 in
Seat Height: Laden 648 mm / 25.5 in Unladen 681 mm / 26.8 in
Gross Vehicle Weight Rating: 453.6 kg / 1000 lbs
Dry Weight: 234 kg / 536 lbs
Wet Weight: 260 kg / 573 lbs
Oil Capacity: 2.7 Litres / 2.8 US qrts
Fuel Capacity: 17 Litres / 4.5 gal
