Harley-Davidson Harley Davidson XL 1200X Forty-Eight (2013) technical specifications
Harley-Davidson Harley Davidson XL 1200X Forty-Eight is produced in 2013. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder., displacement 1199 cc / 73.2 cu in. Harley-Davidson Harley Davidson XL 1200X Forty-Eight wet weight is 257.2 kg / 567 lbs. Harley-Davidson Harley Davidson XL 1200X Forty-Eight has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson XL 1200X Forty-Eight |
| Years: | 2013 |
| Engine: | Four stroke, 45° V-Twin, OHV, 2 valves per cylinder. |
| Capacity: | 1199 cc / 73.2 cu in. |
| Bore x Stroke: | 88.8 x 96.8 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.7:1 |
| Exhaust: | Chrome, staggered shorty exhaust with dual slash-cut mufflers |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Ignition: | Digital CDI |
| Starting: | Electric |
| Max Torque: | 107 Nm / 10.9 kgf-m / 79 ft/lbs./ @ 3500 rpm |
| Transmission: | 5 Speed |
| Final Drive: | Belt |
| Primary Drive Chain: | 38/57 ratio |
| Gear Ratio: | 1st 9.315 / 2nd 6.653 / 3rd 4.948 / 4th 4.102 / 5th 3.517:1 |
| Frame: | Mild steel, tubular frame; circular sections; cast junctions Swingarm Mild steel, rectangular tube sections, stamped junctions; MIG welded |
| Front Suspension: | ∅39mm Fork |
| Front Wheel Travel: | 114 mm / 5.7 in. |
| Rear Suspension: | Coil-over; preload dual-adjustable |
| Rear Wheel Travel: | 54 mm / 2.1 in. |
| Front Brakes: | Single ∅300mm disc, 2 x ∅38mm piston calipers |
| Rear Brakes: | Single ∅300mm disc, 2 x ∅38mm piston calipers |
| Front Wheel: | Black, laced steel spokes |
| Rear Wheel: | Black, laced steel spokes |
| Front Tyre: | MT90B16 |
| Rear Tyre: | 150/80-B16 |
| Rake: | 30° |
| Trail: | 107 mm / 4.2 in |
| Dimensions: | Length 2255 mm / 88.7 in |
| Wheelbase: | 1520 / 59.8 in |
| Seat Height: | Laden 660 mm / 26.0 in Unladen 681 mm / 26.8 in. |
| Ground Clearance: | 100 mm / 3.9 in |
| Wet Weight: | 257.2 kg / 567 lbs |
| Gross Vehicle Weight Rating: | 453.6 kg / 1000 lbs |
| Oil Capacity: | 2.6 L / 0.69 US gal |
| Fuel Capacity: | 13.7 L / 3.6 US gal |
