Technical specifications
|
| Model: |
Harley Davidson XL 1200V Seventy Two |
| Years: |
2016 |
|
Engine:
|
Four stroke, 45° V-Twin, OHV, 2 valves per cylinder.
|
|
Capacity:
|
1199 cc / 73.2 cub in.
|
|
Bore x Stroke:
|
88.8 x 96.8 mm
|
|
Cooling System:
|
Air cooled
|
|
Compression Ratio:
|
9.7:1
|
|
Exhaust:
|
Chrome, staggered shorty exhaust with dual slash-cut mufflers
|
|
Induction:
|
Electronic Sequential Port Fuel Injection (ESPFI)
|
|
Ignition:
|
Digital CDI
|
|
Starting:
|
Electric
|
|
Max Torque:
|
96 Nm / 9.8 kgf-m / 70.8 ft/lbs / @ 3500 rpm
|
|
Transmission:
|
5 Speed
|
|
Final Drive:
|
Belt
|
|
Primary Drive:
|
Chain, 38/57 ratio
|
|
Gear Ratio:
|
1st 9.315 / 2nd 6.653 / 3rd 4.948 / 4th 4.102 / 5th 3.517:1
|
|
Frame:
|
Mild steel, tubular frame; circular sections; cast junctions, Swingarm Mild steel, rectangular tube section, stamped junctions; MIG welded
|
|
Lean Angle, Left:
|
29.8º
|
|
Lean Angle, Right:
|
28.6º
|
|
Front Suspension:
|
39 mm Forks
|
|
Rear Suspension:
|
Coil-over, dual-adjustable preload
|
|
Front Brakes:
|
Single 292 mm disc, 2 piston caliper
|
|
Rear Brakes:
|
Single 292 mm disc, 1 piston calipers
|
|
Front Wheel:
|
Chrome, laced spokes, white wall tyres
|
|
Rear Wheel:
|
Chrome, laced spokes, white wall tyres
|
|
Front Tyre:
|
D402F MH90-21 54H
|
|
Rear Tyre:
|
D401 150/80B16 71H
|
|
Rake:
|
30.1°
|
|
Trail:
|
135 mm / 5.3 in
|
|
Dimensions:
|
Length 2275 mm / 89.5 in
|
|
Wheelbase:
|
1525 / 60.0 in
|
|
Seat Height:
|
Laden 675 mm / 26.6 in. Unladen 710 mm / 28.0 in.
|
|
Dry Weight:
|
248 kg / 546 lbs
|
|
Wet Weight:
|
254 kg / 559 lbs
|
|
Gross Vehicle Weight Rating:
|
453.6 kg / 1000 lbs
|
|
Ground Clearance:
|
135 mm / 5.3 in
|
|
Oil Capacity:
|
2.6 Litres / 2.7 US qrts
|
|
Fuel Capacity:
|
13.7 Litres / 2.1 us gal
|
