Technical specifications
|
| Model: |
Harley Davidson XG 500 Street |
| Years: |
2016-17 |
|
Engine:
|
Four stroke, Revolution X™ 60° V-Twin, SOHC, 4 valves per cyclinder.
|
|
Capacity:
|
494 cc / 30 cu in
|
|
Bore x Stroke:
|
69 x 66 mm
|
|
Cooling System:
|
Liquid cooled
|
|
Compression Ratio:
|
11:01
|
|
Oil Capacity:
|
3.1 L / 3.3 US qt
|
|
Exhaust:
|
Black, 2-into-1
|
|
Induction:
|
Mikuni Single Port Fuel Injection, 35 mm bore
|
|
Ignition:
|
Electronic
|
|
Starting:
|
Electric
|
|
Max Torque:
|
40 Nm / 4.08 kgf-m / 29.5 ft-lb @ 3500 rpm
|
|
Primary Gear:
|
36:68
|
|
Transmission:
|
6 Speed
|
|
Final Drive:
|
Belt
|
|
Gear Ratio:
|
1st 14.25 / 2nd 10.07 / 3rd 7.45 / 4th 5.99 / 5th 5.04 / 6th 4.53:1
|
|
Lean Angle, Left:
|
28.5º
|
|
Lean Angle, Right:
|
28.5º
|
|
Front Brakes:
|
Single disc, 2 piston floating caliper
|
|
Rear Brakes:
|
Single disc, 2 piston floating caliper
|
|
Front Wheel:
|
Black, 7-Spoke Cast Aluminum with Machined Rim Highlights
|
|
Rear Wheel:
|
Black, 7-Spoke Cast Aluminum with Machined Rim Highlights
|
|
Front Tyre:
|
100/80 R17
|
|
Rear Tyre:
|
140/75 R15
|
|
Rake:
|
32°
|
|
Trail:
|
110 mm / 4.5 in.
|
|
Dimension:
|
Length: 2225 mm / 87.6 in.
|
|
Wheelbase:
|
1534 mm / 60.4 in.
|
|
Seat Height:
|
Laden 654 mm / 25.7 in. Unladen 709 mm / 27.9 in.
|
|
Ground Clearance:
|
145 mm / 5.7 in.
|
|
Dry Weight:
|
206 kg / 455 lbs
|
|
Wet Weight:
|
222 kg / 489 lbs
|
|
Fuel Capacity:
|
13.1 Litres / 3.5 US gal
|
