Harley-Davidson Harley Davidson VRSCF V-Rod Muscle (2013) technical specifications

Harley-Davidson Harley Davidson VRSCF V-Rod Muscle is produced in 2013. Engine is Four stroke, 60° V-twin, DOHC, 4 valve per cylinder, Revolution., displacement 1247 cc / 76.1 cu in , produces power 91 kW / 122 hp @ 8250 rpm and 115 Nm / 11.7 kgf-m / 85 ft/lbs @ 6500 rpm. Harley-Davidson Harley Davidson VRSCF V-Rod Muscle top speed is 223.5 km/h / 138.9 mph. Harley-Davidson Harley Davidson VRSCF V-Rod Muscle weighs 292.0 kg / 644 lbs. Harley-Davidson Harley Davidson VRSCF V-Rod Muscle has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson VRSCF V-Rod Muscle
Years:	2013
Engine:	Four stroke, 60° V-twin, DOHC, 4 valve per cylinder, Revolution.
Capacity:	1247 cc / 76.1 cu in
Bore x Stroke:	105 x 72 mm
Cooling System:	Liquid cooled
Compression Ratio:	11.5:1
Exhaust:	Satin chrome, dual side exhaust system with black end caps
Induction:	Electronic Sequential Port Fuel Injection
Ignition:	Digital CDI
Starting:	Electric
Max Power:	91 kW / 122 hp @ 8250 rpm
Max Torque:	115 Nm / 11.7 kgf-m / 85 ft/lbs @ 6500 rpm
Transmission:	5 Speed
Final Drive:	Belt
Primary Drive:	Gear, 64/117 ratio
Gear Ratio:	1st 110.969 / 2nd 7.371 / 3rd 5.900 / 4th 5.095 / 5th 4.563:1
Frame:	Steel perimeter upper frame with hydroformed main rails and bolt-on lower frame rails; MIG welded Swingarm Polished, one-piece cast aluminum
Lean Angle, Left:	32º
Lean Angle, Right:	32º
Front Suspension:	Huge 43 mm forks
Rear Suspension:	Twin coil over adjustable shock
Front Brakes:	2 x 300mm discs, 4 piston calipers
Rear Brakes:	Single 300 mm disc, 4 piston caliper
Wheels, Front and Rear:	Black, 5-spoke, cast aluminum
Front Tyre:	120/70ZR-19 60W
Rear Tyre:	240/40R-18 79V
Rake (steering head):	34°
Trail:	142 mm / 5.6 in
Dimensions:	Length 2410 mm / 94.9 in
Wheelbase:	1700 mm / 66.9 in
Ground Clearance:	105 mm / 4.1 in
Seat Height:	Unladen 705 mm / 27.8 in.
Gross Vehicle Weight Rating:	488.0 kg / 1075 lb
Dry Weight:	292.0 kg / 644 lbs
Wet Weight:	307.0 kg / 677 lbs
Oil Capacity:	4.7 Litres / 5 US qts
Fuel Capacity:	18.9 Litres / 5.0 US gal
Consumption Average:	6.2 L/100 km / 16.2 km/l 38.1 US mpg
Standing ¼ Mile:	12.0 sec
Top Speed:	223.5 km/h / 138.9 mph
