Harley-Davidson Harley Davidson Street Glide Special (2018) technical specifications
Harley-Davidson Harley Davidson Street Glide Special is produced in 2018. Engine is Four stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder, displacement 1746 cc / 107 cub in Harley-Davidson Harley Davidson Street Glide Special weighs 362 kg / 798 lbs. Harley-Davidson Harley Davidson Street Glide Special has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson Street Glide Special |
| Years: | 2018 |
| Engine: | Four stroke, V-Twin, Milwaukee-Eight 107, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder |
| Capacity: | 1746 cc / 107 cub in |
| Bore x Stroke: | 100 x 111 mm / 3.937 x 4.374 in |
| Cooling System: | Air cooled |
| Compression Ratio: | 10.0:1 |
| Exhaust: | Black, 2-1-2 dual exhaust with tapered mufflers |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Lubrication: | Pressurized, dry-sump with oil cooler |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starting: | Electric |
| Max Torque: | 154 Nm / 113.6 lb-ft @ 3250 rpm |
| Clutch: | Hydraulically actuated 9 plate wet, Assist & Slip |
| Transmission: | 6 Speed |
| Final Drive: | Belt |
| Primary Drive: | Chain, 34/46 ratio |
| Gear Ratio: | 1st 9.593 2nd 6.65 3rd 4.938 4th 4.0 5th 3.407 6th 2.875 |
| Frame: | Mild steel, square-section backbone with twin downtubes |
| Front Suspension: | 41.3 mm telescopic, cartridge-style damping, |
| Front Wheel Travel: | 117 mm / 4.6 in |
| Rear Suspension: | Short, air-adjustable shock, |
| Rear Wheel Travel: | 51 mm / 2.0 in |
| Front Brakes: | Caliper Type 32 mm, 4-piston fixed |
| Rear Brakes: | Caliper Type 32 mm, 4-piston fixed |
| Front Wheel: | 9 Black, Talon Cast Aluminum |
| Rear Wheel: | Black, Talon Cast Aluminum |
| Front Tyre: | 130/60B19 61H |
| Rear Tyre: | 180/65B16 81H |
| Rake: | 26° |
| Fork Angle: | 29.2° |
| Trail: | 173mm / 6.8 in |
| Dimensions: | Length 2425 mm / 96.5 in |
| Wheelbase: | 1625 mm / 64 in |
| Seat Height: | Laden 7 663 mm / 26.1 in Unladen 690 mm / 27.2 in |
| Ground Clearance: | 125 mm / 4.9 in |
| Dry Weight: | 362 kg / 798 lbs |
| Wet Weight: | 379 kg / 836 lbs |
| Fuel Capacity: | 22.7 Litres / US 6.0 gal |
