Harley-Davidson Harley Davidson Softail Breakout 114 - 115th Annivarsary (2018) technical specifications

Harley-Davidson Harley Davidson Softail Breakout 114 - 115th Annivarsary is produced in 2018. Engine is Four stroke, V-Twin, 2 Milwaukee-Eight® 114, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder, displacement 1868 cc / 113.9 cu-in Harley-Davidson Harley Davidson Softail Breakout 114 - 115th Annivarsary weighs 294 kg / 648 lbs. Harley-Davidson Harley Davidson Softail Breakout 114 - 115th Annivarsary has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson Softail Breakout 114 - 115th Annivarsary
Years:	2018
Engine:	Four stroke, V-Twin, 2 Milwaukee-Eight® 114, Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters, 4 valves per cylinder
Capacity:	1868 cc / 113.9 cu-in
Bore x Stroke:	102 x 114.3 mm
Cooling System:	Air cooled
Compression Ratio:	10.5:1
Exhaust:	2-into-1-into-2 dual side, catalyst in muffler
Induction:	Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
Lubrication:	Pressurized, dry-sump with oil cooler
Ignition:	Single-fire, non-wasted, map-controlled spark ignition
Starting:	Electric
Max Torque:	155 Nm / 114.3 lb-ft @ 3,500
Clutch:	Multi-plate, wet
Transmission:	6 Speed
Primary Drive:	Chain, 34/46 ratio
Final Drive:	Belt
Gear Ratio:	1st 9.311 / 2nd 6.454 / 3rd 4.793 / 4th 3.882 / 5th 3.307 / 6th 2.79
Lean Angle, Left:	26.8º
Lean Angle, Right:	26.8º
Front Suspension:	Showa Inverted forks
Rear Suspension:	Mono Shock
Front Brakes:	2 x Disc, 4 piston caliper
Rear Brakes:	Single disc, 2 piston floating caliper
Wheels:	Gloss black, Gasser II cast aluminum
Front Tyre:	130/60B21,63H,BW
Rear Tyre:	240/40R18,79V,BW
Rake:	34º
Trail:	145 mm / 5.7 in
Dimensions:	Length 2370 mm / 93.3 in
Wheelbase:	1695 mm / 66.7 in
Ground Clearance:	115 mm / 4.5 in
Seat Height:	665 mm / 26.2 in
Dry Weight:	294 kg / 648 lbs
Wet Weight:	305 kg / 672 lbs
Fuel Capacity:	13.2 Litres / 3.5 US gal
Oil Capacity (with filter):	4.7 Litres / 5 US qts
Fuel Consumption Average:	5.5 L/100 km / 18.2 km/l / 42.8 US mpg
