Harley-Davidson Harley Davidson FXSTB/I Softail Night Train (2005-06) technical specifications
Harley-Davidson Harley Davidson FXSTB/I Softail Night Train is produced in 2005-06. Engine is Four stroke, 45° V-Twin, Twin Cam 88® vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder, displacement 1449 cc / 88.4 cu-in , produces power 67 hp / 48.8 kW @ 5200 rpm and 116.6 Nm / 86 lb-ft @ 3500rpm. Harley-Davidson Harley Davidson FXSTB/I Softail Night Train weighs 286 kg / 630 lbs. Harley-Davidson Harley Davidson FXSTB/I Softail Night Train has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FXSTB/I Softail Night Train |
| Years: | 2005-06 |
| Engine: | Four stroke, 45° V-Twin, Twin Cam 88® vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder |
| Capacity: | 1449 cc / 88.4 cu-in |
| Bore x Stroke: | 95.3 x 101.6 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 8.9:1 |
| Exhaust: | Staggered shorty duals |
| Lubrication: | Dry sump, internally mounted, crank driven gerotor pressure and dual scavenge pump with spin on 10ì pressurized oil filter |
| Induction: | Carburetion 40 mm constant velocity with enrichener and accelerator pump ESPFI 38 mm throttle bore electronic sequential port fuel injection |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starting: | Electric |
| Max Power: | 67 hp / 48.8 kW @ 5200 rpm |
| Max Torque: | 116.6 Nm / 86 lb-ft @ 3500rpm |
| Clutch: | Wet 9-plate |
| Transmission: | 5 Speed |
| Final Drive: | Belt |
| Frame: | Mild steel, rectangular section backbone w/twin downtubes Swing Arm Tubular mild steel |
| Front Suspension: | 41.3 mm telescopic, “beer can” covers |
| Rear Suspension: | Hidden, horizontal-mounted, coil-over shock |
| Front Brakes: | Single 292mm disc 2 piston caliper |
| Rear Brakes: | Single 292mm disc 2 piston caliper |
| Front Tyre: | MH90-21 54H |
| Rear Tyre: | 150/80B 16 71H / 200/55R17 78V (2006) |
| Rake: | 33.5° |
| Trail: | 127 mm / 5.0 in |
| Dimensions: | Length 2413.0 mm / 95.0 in |
| Wheelbase: | 1699.3 mm / 66.9 in |
| Seat Height: | Laden 640.1 mm / 25.2 in unladen 680.7 mm / 26.8 in |
| Ground Clearance: | 142 mm / 5.6 in |
| Dry Weight: | 286 kg / 630 lbs |
| Wet Weight: | 306 kg / 673 lbs |
| Fuel Capacity: | 18.9 Litres / 5.0 US gal |
