Harley-Davidson Harley Davidson FXSB-SE Softail Breakout CVO (2013) technical specifications
Harley-Davidson Harley Davidson FXSB-SE Softail Breakout CVO is produced in 2013. Engine is Four stroke, Twin Cam 110TM Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder, displacement 1801 cc / 110 cu-in Harley-Davidson Harley Davidson FXSB-SE Softail Breakout CVO wet weight is 322 kg / 728 lbs.. Harley-Davidson Harley Davidson FXSB-SE Softail Breakout CVO has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FXSB-SE Softail Breakout CVO |
| Years: | 2013 |
| Engine: | Four stroke, Twin Cam 110TM Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder |
| Capacity: | 1801 cc / 110 cu-in |
| Bore x Stroke: | 101.6 x 111.1 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.2:1 |
| Exhaust: | Chrome, shorty-dual exhaust with slashdown chrome mufflers and chrome heat shields |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starting: | Electric |
| Max Torque: | 152 Nm / 112 lb-ft @ 3500 rpm |
| Clutch: | Multi-plate, wet |
| Transmission: | 6 Speed |
| Final Drive: | Belt |
| Primary Drive: | Chain, 34/46 ratio |
| Gear Ratio: | 1st 9.03 2nd 6.259 3rd 4.649 4th 3.764 5th 3.207 6th 2.706 |
| Frame: | Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded Swingarm Mild steel, round tube sections, forged junctions; MIG welded |
| Front Suspension: | 41.3 mm telescopic, chrome dust covers, |
| Front Wheel Travel: | 143 mm / 5.6 in |
| Rear Suspension: | Hidden, horizontal-mounted, coil-over, |
| Rear Wheel Travel: | 91 mm / 3.6 in |
| Front Brakes: | Single 292mm disc 4 piston caliper |
| Rear Brakes: | Single 292mm disc 2 piston caliper |
| Wheels Front: | 9 Mirror Chrome Turbine Custom Wheels |
| Wheels Rear: | 9 Mirror Chrome Turbine Custom Wheels |
| Front Tyre: | 130/60B21 63H |
| Rear Tyre: | 240/40R18 79V |
| Rake: | 35° |
| Trail: | 145 mm / 5.7 in |
| Dimensions: | Length 2445 mm / 96.3 in. |
| Wheelbase: | 1710 mm / 67.3 in |
| Seat Height: | 655 mm / 25.8 in |
| Ground Clearance: | 120 mm / 4.7 in |
| Wet Weight: | 322 kg / 728 lbs. |
| Oil Capacity: | 3.3 Litres / 3.5 qt. |
| Fuel Capacity: | 18.9 Litres / 5.0 US gal |
