Harley-Davidson Harley Davidson FLTRU Road Glide Ultra (2013-14) technical specifications

Harley-Davidson Harley Davidson FLTRU Road Glide Ultra is produced in 2013-14. Engine is Four stroke, V-Twin, Twin Cam 103™ Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder, with Integrated Oil-Cooler, displacement 1690 cc / 103.1 cu-in Harley-Davidson Harley Davidson FLTRU Road Glide Ultra weighs 402.8 kg / 888 lbs. Harley-Davidson Harley Davidson FLTRU Road Glide Ultra has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson FLTRU Road Glide Ultra
Years:	2013-14
Engine:	Four stroke, V-Twin, Twin Cam 103™ Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder, with Integrated Oil-Cooler
Capacity:	1690 cc / 103.1 cu-in
Bore x Stroke:	98.4 x 111.1 mm
Cooling System:	Air cooled
Compression Ratio:	9.6:1
Exhaust::	Chrome, 2-1-2 dual exhaust with tapered mufflers
Induction:	Electronic Sequential Port Fuel Injection (ESPFI)
Ignition:	Single-fire, non-wasted, map-controlled spark ignition
Starting:	Electric
Max Torque:	135 Nm / 100 ft/lb @ 3250 rpm
Transmission:	6 Speed
Final Drive:	Belt
Primary Drive:	Chain, 34/46 ratio
Gear Ratio:	1st: 9.593 2nd: 6.65 3rd: 4.938 4th: 4 5th: 3.407 6th: 2.875
Frame:	Mild steel, square-section backbone with twin downtubes
Front Suspension:	41.3 mm telescopic, cartridge-style damping
Rear Suspension:	Short, air-adjustable shock
Front Brakes:	2x 292mm disc 4 piston caliper
Rear Brakes:	Single 292mm disc 4 piston caliper
Wheels:	Optional Style Type: Tubeless Chrome Aluminum Profile Laced
Front Wheel:	Black, 28-spoke Cast Aluminum
Rear Wheel:	Black, 28-spoke Cast Aluminum
Front Tyre:	BW 130/80B17 65H
Rear Tyre:	BW 180/65B16 81H
Rake:	26°
Trail:	170 mm / 6.7 in
Dimensions:	Length 2525 mm / 99.4 in.
Wheelbase:	1630 mm / 64.1 in
Seat Height:	Laden 693 mm / 28.4 in Unladen 739 mm / 29.7 in
Ground Clearance:	125 mm / 4.9 in
Gross Vehicle Weight Rating:	616.9 kg / 1360 lbs
Dry Weight:	402.8 kg / 888 lbs
Wet Weight:	413 kg / 910 lbs
Fuel Capacity:	22.7 Litres / 6.0 US gal
