Harley-Davidson Harley Davidson FLSTN Softail Deluxe (2013) technical specifications
Harley-Davidson Harley Davidson FLSTN Softail Deluxe is produced in 2013. Engine is Four stroke, V-Twin, Twin Cam 103™ Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder, with Integrated Oil-Cooler, displacement 1690 cc / 103.1 cu-in Harley-Davidson Harley Davidson FLSTN Softail Deluxe wet weight is 329.0 kg / 726 lbs. Harley-Davidson Harley Davidson FLSTN Softail Deluxe has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FLSTN Softail Deluxe |
| Years: | 2013 |
| Engine: | Four stroke, V-Twin, Twin Cam 103™ Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder, with Integrated Oil-Cooler |
| Capacity: | 1690 cc / 103.1 cu-in |
| Bore x Stroke: | 98.4 x 111.1 mm |
| Cooling System: | Air cooled |
| Compression Ratio: | 9.6:1 |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starting: | Electric |
| Max Torque: | 132 Nm / 98.8 ft. lbs @ 3250 rpm |
| Clutch: | Multi-plate, wet |
| Transmission: | 6 Speed |
| Final Drive: | Belt |
| Gear Ratio: | 1st 9.311 2nd 6.454 3rd 4.793 4th 3.882 5th 3.307 6th 2.79 |
| Frame: | Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded |
| Front Suspension: | 41.3 mm telescopic, chrome dust covers |
| Rear Suspension: | Hidden, horizontal-mounted, coil-over shock |
| Front Brakes: | Single 292mm disc 4 piston caliper |
| Rear Brakes: | Single 292mm disc 2 piston caliper |
| Front Tyre: | MT90-16 72H |
| Rear Tyre: | MU85B16 77H |
| Rake: | 32.1° |
| Trail: | 147 mm / 5.8 in |
| Dimensions: | Length 2400 mm / 94.4 in |
| Wheelbase: | 1635 mm / 64.2 in |
| Seat Height: | Laden 622 mm / 24.5 in Unladen 670 mm / 25.9 in |
| Gross Vehicle Weight Rating: | 526.0 kg / 1160 lbs |
| Wet Weight: | 329.0 kg / 726 lbs |
| Ground Clearance: | 114 mm / 4.5 in |
| Oil Capacity: | 3.3 Litres |
| Fuel Capacity: | 18.9 Litres / 5.0 US gal |
