Harley-Davidson Harley Davidson FLHTK Electra Glide Ultra Limited (2012) technical specifications
Harley-Davidson Harley Davidson FLHTK Electra Glide Ultra Limited is produced in 2012. Engine is Four stroke, Twin Cam 103™ with integrated oil cooler Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder, displacement 1690 cc / 103.1 cub in. Harley-Davidson Harley Davidson FLHTK Electra Glide Ultra Limited wet weight is 414 kg / 896 lbs. Harley-Davidson Harley Davidson FLHTK Electra Glide Ultra Limited has 3 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FLHTK Electra Glide Ultra Limited |
| Years: | 2012 |
| Engine: | Four stroke, Twin Cam 103™ with integrated oil cooler Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder |
| Capacity: | 1690 cc / 103.1 cub in. |
| Bore x Stroke: | 98.4 x 111.25 mm |
| Cooling System: | Air/Liquid cooled, |
| Compression Ratio: | 10.0:1 |
| Exhaust: | Chrome, 2-1-2 dual exhaust with tappered mufflers |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starting: | Electric |
| Max Torque: | 143 Nm / 105.4 ft/lb @ 3750 rpm |
| Clutch: | Multi-plate, wet |
| Transmission: | 6 Speed |
| Final Drive: | Belt |
| Gear Ratio: | 1st 9.593 / 2nd 6.650 / 3rd 4.938 / 4th 4.000 / 5th 3.407 / 6th 2.875 |
| Frame: | Mild steel; tubular frame; two-piece stamped and welded backbone; cast and forged junctions; twin downtubes; bolt-on rear frame with forged fender supports; MIG welded |
| Front Suspension: | 41.3 mm telescopic, cartridge-style damping |
| Rear Suspension: | Swingarm Mild steel; two-piece drawn and welded section; forged junctions; MIG welded, Rear Shocks Air-adjustable |
| Front Brakes: | 2x 300mm disc 4 piston caliper ABS |
| Rear Brakes: | Single 300mm disc 4 piston caliper ABS |
| Wheels Front: | Contrast Chrome Impeller Cast Aluminum |
| Wheels Rear: | Contrast Chrome Impeller Cast Aluminum |
| Front Tyre: | BW 130/80B17 65H |
| Rear Tyre: | BW 180/65B16 81H |
| Rake: | 26° |
| Trail: | 170 mm / 6.6 IN |
| Dimensions: | Length 2600 mm / 102.4 in. |
| Wheelbase: | 1625 mm / 64 in. |
| Seat Height: | Laden 695 mm / 27.3 in Unladen 740 mm / 29.1 in |
| Gross Vehicle Weight Rating: | 616.9 kg / 1360 lbs |
| Wet Weight: | 414 kg / 896 lbs |
| Oil Capacity: | 3.8 Litres / 4 qt. |
| Fuel Capacity: | 22.7 Litres / 6.0 US gal |
