Harley-Davidson Harley Davidson FLHS 1340 Electra Glide (1988) technical specifications
Harley-Davidson Harley Davidson FLHS 1340 Electra Glide is produced in 1988. Engine is Four stroke, 45° V-Twin, OHV, 2 valves per cylinder., displacement 1337 cc / 81.7 cu-in , produces power 67 hp / 48.9 hp @ 5000 rpm and 69 lb-ft @ 3000 rpm. Harley-Davidson Harley Davidson FLHS 1340 Electra Glide weighs 343 kg / 756 lbs. Harley-Davidson Harley Davidson FLHS 1340 Electra Glide has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FLHS 1340 Electra Glide |
| Years: | 1988 |
| Engine: | Four stroke, 45° V-Twin, OHV, 2 valves per cylinder. |
| Capacity: | 1337 cc / 81.7 cu-in |
| Cooling System: | Air cooled |
| Bore x Stroke: | 88.8 x 108.0 mm |
| Compression Ratio: | 8.5:1 |
| Induction: | 38mm Keihin Carburettor |
| Ignition: | Solid state electronic |
| Starting: | Electric |
| Max Power: | 67 hp / 48.9 hp @ 5000 rpm |
| Max Torque: | 69 lb-ft @ 3000 rpm |
| Transmission / Drive: | 4 Speed |
| Final Drive: | Chain |
| Front Suspension: | Telescopic forks |
| Rear Suspension: | Dual shocks swinging arm |
| Front Brakes: | 2x 292mm discs 4 piston calipers |
| Rear Brakes: | Single 292mm disc 4 piston caliper |
| Front Tyre: | 90/90-16 |
| Rear Tyre: | 150/85-16 |
| Dry Weight: | 343 kg / 756 lbs |
| Fuel Capacity: | 19 Litres / 5.0 US gal |
