Harley-Davidson Harley Davidson FLHR-SE5 Road King CVO 110th Anniversary Edition (2013) technical specifications
Harley-Davidson Harley Davidson FLHR-SE5 Road King CVO 110th Anniversary Edition is produced in 2013. Engine is Four stroke, 45° V-Twin, Twin Cam 110 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder, displacement 1802 cc / 110 cu-in Harley-Davidson Harley Davidson FLHR-SE5 Road King CVO 110th Anniversary Edition weighs 355 kg / 779 lbs. Harley-Davidson Harley Davidson FLHR-SE5 Road King CVO 110th Anniversary Edition has 2 photos.
Technical specifications
+ Add to 'Compare list'| Model: | Harley Davidson FLHR-SE5 Road King CVO 110th Anniversary Edition |
| Years: | 2013 |
| Engine: | Four stroke, 45° V-Twin, Twin Cam 110 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder |
| Capacity: | 1802 cc / 110 cu-in |
| Bore x Stroke: | 101.6 x 111.1 mm |
| Cooling System: | Air cooled |
| Lubrication: | Pressurized, dry-sump |
| Compression Ratio: | 9.7:1 |
| Exhaust: | Chrome, 2-1-2 dual exhaust with tapered mufflers |
| Induction: | Electronic Sequential Port Fuel Injection (ESPFI) |
| Ignition: | Single-fire, non-wasted, map-controlled spark ignition |
| Starring: | Electric |
| Max Torque: | 156 Nm / 115 lb-ft @ 3000 rpm |
| Transmission: | 6 Speed |
| Final Drive: | Belt |
| Primary Drive: | Chain, 34/46 ratio |
| Gear Ratio: | 1st 9.593 2nd 6.65 3rd 4.938 4th 4.0 5th 3.407 6th 2.875 |
| Frame: | Mild steel, square-section backbone with twin downtubes |
| Front Suspension: | 41.3 mm telescopic, cartridge-style damping |
| Rear Suspension: | Short, air-adjustable shock |
| Front Brakes: | 2x 292mm disc 4 piston caliper |
| Rear Brakes: | Single 292mm disc 4 piston caliper |
| Wheels: | Optional Style Type Tubeless Chrome Aluminum Profile Laced |
| Front Wheel: | Black and Chrome, 28-spoke Cast Aluminum |
| Rear Wheel: | Black and Chrome, 28-spoke Cast Aluminum |
| Front Tyre: | 130/80B17 65H |
| Rear Tyre: | 180/65B16 81H |
| Rake: | 26° |
| Trail: | 170 mm / 6.7 in |
| Dimensions: | Length 2465 mm / 96.5 in |
| Wheelbase: | 1625 mm / 64 in |
| Seat Height: | Laden2 673 mm / 26.5 in Unladen 711 mm / 28.0 in. |
| Gross Vehicle Weight Rating: | 16.9 kg / 1360 lbs |
| Dry Weight: | 355 kg / 779 lbs |
| Wet Weight: | 368.3 kg / 812 lb |
| Ground Clearance: | 145 mm / 5.7 in |
| Oil Capacity: | 3.3 Litres / 0.87 US gal |
| Fuel Capacity: | 22.7 Litres / 6.0 gal |
