Harley-Davidson Harley Davidson Dyna Street Bob (2013) technical specifications

Harley-Davidson Harley Davidson Dyna Street Bob is produced in 2013. Engine is Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder, displacement 1584 cc / 96 cu-in Harley-Davidson Harley Davidson Dyna Street Bob wet weight is 302.6 kg / 667 lbs.. Harley-Davidson Harley Davidson Dyna Street Bob has 4 photos.

Technical specifications

+ Add to 'Compare list'

Model:	Harley Davidson Dyna Street Bob
Years:	2013
Engine:	Four stroke, 45° V-Twin, Twin Cam 96 vibration isolation-mounted Valves Pushrod-operated overhead valves; w/ hydraulic self-adjusting lifters; two valves per cylinder
Capacity:	1584 cc / 96 cu-in
Bore x Stroke:	95.3 x 111.1 mm
Cooling System:	Air cooled
Compression Ratio:	9.2:1
Induction:	Electronic Sequential Port Fuel Injection (ESPFI)
Ignition:	Single-fire, non-wasted, map-controlled spark ignition
Starting:	Electric
Max Torque:	124.7 Nm / 92 ft/ lbs. @ 3000 rpm
Transmission:	6 Speed
Final Drive:	Belt
Primary Drive:	Chain, 34/46 ratio
Gear Ratio:	1st 9.311 2nd 6.454 3rd 4.793 4th 3.882 5th 3.307 6th 2.79
Frame:	Mild steel, tubular frame; rectangular section backbone; stamped, cast and forged junctions, forged fender supports; MIG welded
Front Suspension:	49 mm with polished aluminum fork triple clamp and dual-rate springs,
Rear Suspension:	Coil over shock ,
Front Brakes:	Single 300mm disc 4 piston caliper
Rear Brakes:	Single 292mm disc 2 piston caliper
Front Tyre:	100/90-19 57H
Rear Tyre:	160/70-17 73V
Rake:	29°
Trail:	120 mm / 4.7 in
Dimensions:	Length 2357 mm / 92.8 in Width 953 mm / 37.5 in. Height 1280 mm / 50.4 in
Wheelbase:	1630 mm / 64.2 in
Seat Height:	Laden 648 mm / 25.5 in. Unladen 678 mm / 26.7 in.
Gross Vehicle Weight Rating:	492.2 kg / 1085 lbs
Wet Weight:	302.6 kg / 667 lbs.
Oil Capacity:	2.8 Litres
Fuel Capacity:	17.8 Litres / 4.7 gal
